1 Port PCI Express PCIe Gigabit Network Server Adapter NIC Card - Dual Profile
Model ST1000SPEX2EAN 6213759768884
43 specifications
- Speed1000 Mbit/s
- ConnectivityWired
- Weight40 g
- InternalYes
- Operating temperature (T-T)0 - 70 °C
- Width120.3 mm
Overview
- Speed
- 1000 Mbit/s
- Connectivity
- Wired
- Weight
- 40 g
- Internal
- Yes
- Operating temperature (T-T)
- 0 - 70 °C
- Width
- 120.3 mm
- Brand
- StarTech.com
- Category
- Network Card
- Model
- ST1000SPEX2
- Part number
- ST1000SPEX2
- EAN / UPC
- 6213759768884, 065030849265, 132017783161, 163120668205 +10 more
- Also known as
- StarTech.com 1 Port PCI Express PCIe Gigabit Network Server Adapter NIC Card - Dual Profile
Specifications
43 specifications in 11 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | PCI Express |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 1 |
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 1000 Mbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000BaseT(X) |
| Wi-Fi | No |
| Wake-on-LAN ready | Yes |
| Auto MDIX IEEE | Yes |
| Full duplex | Yes |
| Jumbo frames | 9000 |
| Jumbo frames support | Yes |
| Supported network protocols | CSMA/CD |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Chipset | Realtek RTL8111E |
| LED indicators | Activity, Link |
| Mean time between failures (MTBF) | 376212 h |
| Certification | CE, FCC |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 2000 Professional, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home B |
| Mac operating systems supported | Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | 0 - 100 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 120.3 mm |
| Depth | 67.9 mm |
| Height | 18 mm |
| Weight | 40 g |
Packaging data
| Specification | Value |
|---|---|
| Drivers included | Yes |
| Low-profile bracket | Yes |
| Package width | 142 mm |
| Package depth | 171 mm |
| Package height | 32 mm |
| Package weight | 126 g |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
Other features
| Specification | Value |
|---|---|
| Supported data transfer rates | 10/100/1000 Mbit/s |
