StarTech.com 1-Port 2.5Gbps NBASE-T PoE Network Card, Intel I225-V, 802.3af/at PoE+ Multi-Gigabit NIC, PCI Express Server LAN Card, SATA Powered Desktop Etherne
StarTech.com

1-Port 2.5Gbps NBASE-T PoE Network Card, Intel I225-V, 802.3af/at PoE+ Multi-Gigabit NIC, PCI Express Server LAN Card, SATA Powered Desktop Etherne

Model PR12GIP-NETWORK-CARDEAN 065030903493

40 specifications
  • Speed2500 Mbit/s
  • ConnectivityWired
  • Weight62 g
  • ColourBlack
  • InternalYes
  • Output voltage48 V
See all specifications

Overview

Speed
2500 Mbit/s
Connectivity
Wired
Weight
62 g
Colour
Black
Internal
Yes
Output voltage
48 V
Brand
StarTech.com
Category
Network Card
Model
PR12GIP-NETWORK-CARD
Part number
PR12GIP-NETWORK-CARD
EAN / UPC
065030903493
Also known as
StarTech.com 1-Port 2.5Gbps NBASE-T PoE Network Card, Intel I225-V, 802.3af/at PoE+ Multi-Gigabit NIC, PCI Express Server LAN Card, SATA Powered Desktop Etherne

Specifications

40 specifications in 13 groups

Ports & interfaces

Connectivity technologyWired
Host interfacePCI Express
InterfaceEthernet
Ethernet LAN (RJ-45) ports1
Power over Ethernet (PoE) ports quantity1
PCI version2.0

Network

Maximum data transfer rate2500 Mbit/s
Networking standardsIEEE 1588, IEEE 802.1Q, IEEE 802.1as, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3i, IEEE 802.3u
Ethernet LAN data rates10,100,1000,2500 Mbit/s
Wake-on-LAN readyYes
Quality of Service (QoS) supportYes

Design

InternalYes
Component forPC/Server
Product colourBlack
ChipsetIntel I225-V
LED indicatorsYes

Power

Output voltage48 V

System requirements

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterp
Linux operating systems supportedYes
Other operating systems supportedVMware vSphere ESXi
Server operating systems supportedWindows Server 2019, Windows Server 2022

Operational conditions

Operating temperature (T-T)0 - 55 °C
Storage temperature (T-T)-10 - 70 °C
Operating relative humidity (H-H)5 - 90%

Sustainability

Sustainability complianceYes

Weight & dimensions

Width54 mm
Depth119 mm
Height16 mm
Weight62 g

Packaging data

Package width156 mm
Package depth216 mm
Package height38 mm
Package weight70 g

Packaging content

Quick installation guideYes

Technical details

Compliance certificatesRoHS

Logistics data

Master (outer) case width440 mm
Master (outer) case length374 mm
Master (outer) case height318 mm
Products per master (outer) case40 pc(s)

Other features

Number of SATA power connectors1
