1-Port 10G Open SFP+ Network Card - PCIe - Intel Chip - MM/SM
Model PEX10000SFPIEAN 065030866163
42 specifications
- Speed10000 Mbit/s
- ConnectivityWired
- Weight102 g
- ColourBlack
- InternalYes
- Operating temperature (T-T)5 - 50 °C
Overview
- Speed
- 10000 Mbit/s
- Connectivity
- Wired
- Weight
- 102 g
- Colour
- Black
- Internal
- Yes
- Operating temperature (T-T)
- 5 - 50 °C
- Brand
- StarTech.com
- Category
- Network Card
- Model
- PEX10000SFPI
- Part number
- PEX10000SFPI
- EAN / UPC
- 065030866163
- Also known as
- StarTech.com 1-Port 10G Open SFP+ Network Card - PCIe - Intel Chip - MM/SM
Specifications
42 specifications in 11 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | PCI Express |
| Interface | Fiber |
| Fiber optic connector | SFP+ |
| Fiber ports quantity | 1 |
| PCI version | 2.0 |
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 10000 Mbit/s |
| Networking standards | IEEE 802.1Q, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3aq, IEEE 802.3x |
| Fiber ethernet cabling technology | 10GBASE-LR, 10GBASE-LRM, 10GBASE-SR |
| Full duplex | Yes |
| Jumbo frames | 15000 |
| Jumbo frames support | Yes |
| VLAN tagging | Yes |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Component for | PC |
| Product colour | Black |
| Chipset | Intel® 82599 |
| Certification | CE, FCC, REACH |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterpri |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 18 mm |
| Depth | 135 mm |
| Height | 120 mm |
| Weight | 102 g |
Packaging data
| Specification | Value |
|---|---|
| Low-profile bracket | Yes |
| Package width | 142 mm |
| Package depth | 172 mm |
| Package height | 32 mm |
| Package weight | 178 g |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 359 mm |
| Master (outer) case length | 585 mm |
| Master (outer) case height | 309 mm |
| Products per master (outer) case | 80 pc(s) |
Other features
| Specification | Value |
|---|---|
| Quick start guide | Yes |
| Flow control support | Yes |
