PCI Wireless N Adapter - 300 Mbps PCI 802.11 b/g/n Network Adapter Card – 2T2R 2.2 dBi
Model PCI300WN2X2EAN 5554442317332
33 specifications
- Speed300 Mbit/s
- ConnectivityWireless
- Weight50 g
- ColourGreen
- InternalYes
- Operating temperature (T-T)0 - 55 °C
Overview
- Speed
- 300 Mbit/s
- Connectivity
- Wireless
- Weight
- 50 g
- Colour
- Green
- Internal
- Yes
- Operating temperature (T-T)
- 0 - 55 °C
- Brand
- StarTech.com
- Category
- Network Card
- Model
- PCI300WN2X2
- Part number
- PCI300WN2X2
- EAN / UPC
- 5554442317332, 065030848763, 108848201105, 132018030875 +6 more
- Also known as
- StarTech.com PCI Wireless N Adapter - 300 Mbps PCI 802.11 b/g/n Network Adapter Card – 2T2R 2.2 dBi
Specifications
33 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wireless |
| Host interface | PCI |
| Interface | WLAN |
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 300 Mbit/s |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi | Yes |
| Wi-Fi band | Single-band (2.4 GHz) |
| Frequency range | 2.4 - 2.484 GHz |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Security algorithms | TKIP, WEP, WPA |
| Full duplex | Yes |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Product colour | Green |
| Antenna | Yes |
| Antenna connector type | RP-SMA |
| Chipset | Ralink RT3062F |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows |
| Linux operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 53 mm |
| Depth | 129 mm |
| Height | 19 mm |
| Weight | 50 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 136 mm |
| Package depth | 163 mm |
| Package height | 32 mm |
| Package weight | 155 g |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Other features
| Specification | Value |
|---|---|
| Gain | 2.2 dBi |
| Supported data transfer rates | 11, 54Mbps |
