MSI MS-6852 WLAN / Bluetooth 54 Mbit/s

MSI MS-6852 WLAN / Bluetooth 54 Mbit/s

Model MS-6852Part no. 6852

31 specifications
  • Speed54 Mbit/s
  • ConnectivityWired & Wireless
  • AntennaYes
  • Output voltage5 V
  • Operating temperature (T-T)0 - 60 °C
  • Width119.9 mm
See all specifications

Overview

Speed
54 Mbit/s
Connectivity
Wired & Wireless
Antenna
Yes
Output voltage
5 V
Operating temperature (T-T)
0 - 60 °C
Width
119.9 mm
Brand
MSI
Category
Network Card
Model
MS-6852
Part number
6852
Also known as
MSI MS-6852 WLAN / Bluetooth 54 Mbit/s

Specifications

31 specifications in 9 groups

Ports & interfaces

Connectivity technologyWired & Wireless
Host interfacePCI
InterfaceWLAN / Bluetooth
USB version1.1

Network

Maximum data transfer rate54 Mbit/s
Networking standardsIEEE 802.11b, IEEE 802.11g
Wi-FiYes
Wi-Fi bandSingle-band (2.4 GHz)
Frequency range2.4 - 2.4835 GHz
Top Wi-Fi standard802.11g
Wi-Fi standards802.11b, 802.11g
Spread spectrum methodFHSS
ModulationCCK, DBPSK, DQPSK
Channels quantity (EU)14 channels
Bluetooth version1.2

Design

AntennaYes
Antenna designExternal
LED indicatorsBluetooth, Power, WLAN
CertificationFCC, CE, Wi-Fi+WPA, WHQL

Power

Output voltage5 V
Power consumption440 mA
USB poweredYes

System requirements

Windows operating systems supportedWindows 2000, Windows 2000 Professional, Windows 98SE, Windows ME, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Operational conditions

Operating temperature (T-T)0 - 60 °C
Storage temperature (T-T)-20 - 100 °C

Weight & dimensions

Width119.9 mm
Depth83.2 mm

Packaging data

Drivers includedYes

Other features

Gain3 dBi
Antennas quantity1
Transmit power range14 - 17 dBmW
