Gigabit Fiber PCIe Network Card, PCIe 4X, 2 x SFP
Model GNC-0122EAN 4015867191071
35 specifications
- ConnectivityWired
- Weight83 g
- ColourAluminium
- Fiber ethernet cabling technology1000BASE‑LX, 1000BASE‑SX
- InternalYes
- Operating temperature (T-T)0 - 55 °C
Overview
- Connectivity
- Wired
- Weight
- 83 g
- Colour
- Aluminium
- Fiber ethernet cabling technology
- 1000BASE‑LX, 1000BASE‑SX
- Internal
- Yes
- Operating temperature (T-T)
- 0 - 55 °C
- Brand
- LevelOne
- Category
- Network Card
- Model
- GNC-0122
- Part number
- GNC-0122
- EAN / UPC
- 4015867191071, 4015867224212
- Also known as
- LevelOne Gigabit Fiber PCIe Network Card, PCIe 4X, 2 x SFP
Specifications
35 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | PCI Express |
| Interface | Fiber |
| Fiber optic connector | SFP |
| Fiber ports quantity | 2 |
| PCI version | 2.0 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 1588, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ad |
| Fiber ethernet cabling technology | 1000BASE‑LX, 1000BASE‑SX |
| Wake-on-LAN ready | Yes |
| Jumbo frames support | Yes |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Product colour | Aluminium |
| LED indicators | Activity, Link |
| Country of origin | China |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 2000, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, |
| Server operating systems supported | Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012 R2 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 160 mm |
| Depth | 68 mm |
| Height | 17 mm |
| Weight | 83 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 145 mm |
| Package depth | 220 mm |
| Package height | 30 mm |
| Package weight | 62 g |
Packaging content
| Specification | Value |
|---|---|
| Mounting brackets included | Yes |
| Manual | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
Other features
| Specification | Value |
|---|---|
| Quick start guide | Yes |
| Intel Virtual Machine Device Queues (VMDq) | Yes |
| Power supply | 2.2 W |
