Gigabit PCI Network Card
Model GNC-0105TEAN 4015867135853
33 specifications
- Speed2000 Mbit/s
- ConnectivityWired
- Weight60 g
- ColourAluminium
- InternalYes
- Operating temperature (T-T)0 - 50 °C
Overview
- Speed
- 2000 Mbit/s
- Connectivity
- Wired
- Weight
- 60 g
- Colour
- Aluminium
- Internal
- Yes
- Operating temperature (T-T)
- 0 - 50 °C
- Brand
- LevelOne
- Category
- Network Card
- Model
- GNC-0105T
- Part number
- GNC-0105T
- EAN / UPC
- 4015867135853, 878742001209, 4015867111260, 4054318203796 +1 more
- Also known as
- LevelOne Gigabit PCI Network Card
Specifications
33 specifications in 11 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | PCI |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 1 |
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 2000 Mbit/s |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000BaseT(X) |
| Wake-on-LAN ready | Yes |
| Full duplex | Yes |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Product colour | Aluminium |
| LED indicators | Activity, LAN, Link |
| Country of origin | China |
| Certification | FCC Class, CE |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 2000, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, |
| Server operating systems supported | Windows Server 2003, Windows Server 2008, Windows Server 2008 R2 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 115 mm |
| Depth | 140 mm |
| Height | 17 mm |
| Weight | 60 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 145 mm |
| Package depth | 220 mm |
| Package height | 30 mm |
| Package weight | 62 g |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
Other features
| Specification | Value |
|---|---|
| Quick start guide | Yes |
