EW-7822UTC network card WLAN 867 Mbit/s
Model EW-7822UTC
39 specifications
- Speed867 Mbit/s
- ConnectivityWireless
- Weight40 g
- ColourBlack
- InternalNo
- USB poweredYes
Overview
- Speed
- 867 Mbit/s
- Connectivity
- Wireless
- Weight
- 40 g
- Colour
- Black
- Internal
- No
- USB powered
- Yes
- Brand
- iiyama
- Category
- Network Card
- Model
- EW-7822UTC
- Part number
- EW-7822UTC
- Also known as
- iiyama EW-7822UTC network card WLAN 867 Mbit/s
Specifications
39 specifications in 12 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wireless |
| Host interface | USB |
| Interface | WLAN |
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 867 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi | Yes |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rates supported | 11,54,300,867 Mbit/s |
| Modulation | 16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA2, WPS |
| Bandwidth (first) | 2.4 GHz |
| Bandwidth (second) | 5 GHz |
Design
| Specification | Value |
|---|---|
| Internal | No |
| Product colour | Black |
| Antenna | Yes |
| Antenna design | Internal |
| LED indicators | Activity, Link |
| Certification | CE, FCC |
Power
| Specification | Value |
|---|---|
| USB powered | Yes |
System requirements
| Specification | Value |
|---|---|
| Compatible operating systems | Windows 7/8/8.1/10, Mac OS 10.9 - 10.15 and Linux Kernel: 2.6.24 ~ 4.15 |
| Windows operating systems supported | Windows 7, Windows 8, Windows 8.1 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 16 mm |
| Depth | 8 mm |
| Height | 34 mm |
| Weight | 40 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
Other features
| Specification | Value |
|---|---|
| Antennas quantity | 2 |
| Supported data transfer rates | AC1200 WiFi 5, Max. data transfer rates up to 867Mbps (5GHz) and 300Mbps (2.4GHz) |
| Transmit power range | 20 - 20 dBmW |
