ICY BOX USB 3.0 A-Type to RJ-45 Ethernet port

USB 3.0 A-Type to RJ-45 Ethernet port

Model IB-AC501aPart no. 60498EAN 4250078168843

37 specifications

Speed1000 Mbit/s
ConnectivityWired
Weight19 g
ColourBlack
InternalNo
Width20 mm

See all specifications

Overview

Speed: 1000 Mbit/s
Connectivity: Wired
Weight: 19 g
Colour: Black
Internal: No
Width: 20 mm

Brand: ICY BOX
Category: Network Card
Model: IB-AC501a
Part number: 60498
EAN / UPC: 4250078168843
Also known as: ICY BOX USB 3.0 A-Type to RJ-45 Ethernet port

Specifications

37 specifications in 8 groups

Ports & interfaces

Specification	Value
Connectivity technology	Wired
Host interface	USB
Interface	Ethernet
Ethernet LAN (RJ-45) ports	1
USB ports quantity	1
USB connector form factor	Straight
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)

Network

Specification	Value
Maximum data transfer rate	1000 Mbit/s
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000BaseT(X)
Full duplex	Yes
Jumbo frames support	Yes

Design

Specification	Value
Internal	No
Component for	PC/Laptop
Product colour	Black
LED indicators	Activity
Country of origin	China

Weight & dimensions

Specification	Value
Width	20 mm
Depth	180 mm
Height	15 mm
Weight	19 g

Packaging data

Specification	Value
Drivers included	Yes
Package width	85 mm
Package depth	100 mm
Package height	20 mm
Package weight	59 g

Packaging content

Specification	Value
Manual	Yes

Logistics data

Specification	Value
Harmonized System (HS) code	85176200
Master (outer) case width	215 mm
Master (outer) case length	230 mm
Master (outer) case height	220 mm
Master (outer) case gross weight	2.38 kg
Products per master (outer) case	40 pc(s)

Other features

Specification	Value
Housing material	Plastic
