HP Intel Wireless-AC 9560

HP Intel Wireless-AC 9560

Model Intel Wireless-AC 9560Part no. 4YE31AV

36 specifications
  • Speed1730 Mbit/s
  • ConnectivityWireless
  • TypeWireless
  • Weight2.8 g
  • ColourGreen, Grey
  • InternalYes
See all specifications

Overview

Speed
1730 Mbit/s
Connectivity
Wireless
Type
Wireless
Weight
2.8 g
Colour
Green, Grey
Internal
Yes
Brand
HP
Category
Network Card
Model
Intel Wireless-AC 9560
Part numbers
4YE31AV, 2WR28AV, 2YF22AV, 3UA92AV, 2YJ31AV, 3AA89AV +11 more
Also known as
HP Intel Wireless-AC 9560 Internal WLAN / Bluetooth 1730 Mbit/s

Specifications

36 specifications in 8 groups

Ports & interfaces

Connectivity technologyWireless
Host interfaceM.2
InterfaceWLAN / Bluetooth

Network

Maximum data transfer rate1730 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.11w, IEEE 802.1x
Wi-FiYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rates supported1734 Mbit/s
Security algorithms64-bit WEP, 128-bit WEP, EAP-AKA, EAP-SIM, EAP-TLS, PEAP, TKIP, TTLS, WPA, WPA2, WPA2-PSK
Bandwidth (first)2.4 GHz
Bandwidth (second)5 GHz
Bluetooth version5.0

Design

InternalYes
Product colourGreen, Grey
AntennaYes
SafetyUL, C-UL, CB
CertificationWi-Fi, FIPS, FISMA

System requirements

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64
Linux operating systems supportedYes
Other operating systems supportedChromeOS

Operational conditions

Operating temperature (T-T)0 - 80 °C
Operating relative humidity (H-H)50 - 90%

Weight & dimensions

Width16 mm
Depth1.57 mm
Height12 mm
Weight2.8 g

Packaging data

Quantity per pack1 pc(s)

Other features

Antennas quantity4
Ethernet adapter ARK ID99446
Product typeWireless
Supported Under vProYes
Launch dateQ4'17
Product brief URLhttps://www.intel.com/content/www/us/en/wireless-products/dual-band-wireless-ac-9560-brief.html
StatusLaunched
