4G LTE-Advanced Pro Cat16 WWAN
Model 4G LTE-Advanced Pro Cat16 WWANPart no. B8BD2AAEAN 198990490229
32 specifications
- ConnectivityWireless
- Weight7 g
- Mobile network generation4G
- InternalYes
- Compatible operating systemsWindows 10; Windows 11
- Operating temperature (T-T)-20 - 65 °C
Overview
- Connectivity
- Wireless
- Weight
- 7 g
- Mobile network generation
- 4G
- Internal
- Yes
- Compatible operating systems
- Windows 10; Windows 11
- Operating temperature (T-T)
- -20 - 65 °C
- Brand
- HP
- Category
- Network Card
- Model
- 4G LTE-Advanced Pro Cat16 WWAN
- Part number
- B8BD2AA
- EAN / UPC
- 198990490229, 5715328284357
- Also known as
- HP 4G LTE-Advanced Pro Cat16 WWAN Internal
Specifications
32 specifications in 12 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wireless |
| Interface | WWAN |
Network
| Specification | Value |
|---|---|
| Mobile network generation | 4G |
| Modulation | 256-QAM |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Component for | Laptop |
| Country of origin | China |
| Compatible products | HP EliteBook 6 G1i 13 inch Notebook AI PC; HP EliteBook 6 G1i 14 inch Notebook AI PC; HP EliteBook 6 G1i 16 inch Notebook AI PC; HP ProBook 4 G1i 14 inch Notebook AI PC;HP ProBook 4 G1i 16 inch Notebook AI PC; HP EliteBook 6 G1a 14 inch Notebook AI PC; HP EliteBook 6 G1a 16 inch Notebook AI PC; HP E |
| HP segment | Business |
System requirements
| Specification | Value |
|---|---|
| Compatible operating systems | Windows 10; Windows 11 |
| Windows operating systems supported | Windows 10, Windows 11 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 65 °C |
| Storage temperature (T-T) | -40 - 85 °C |
Sustainability
| Specification | Value |
|---|---|
| Sustainable technologies and materials | At least 30% post-consumer recycled plastic |
| Sustainability compliance | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 52 mm |
| Depth | 30 mm |
| Height | 2.3 mm |
| Weight | 7 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 232 mm |
| Package depth | 148 mm |
| Package height | 10 mm |
| Package weight | 59 g |
Brand-specific features
| Specification | Value |
|---|---|
| HP GTIN (EAN/UPC) | 198990490229 |
Technical details
| Specification | Value |
|---|---|
| General Product Safety Regulation (GPSR) URL | https://support.hp.com/us-en/document/ish_6126692-6126777-16?openCLC=true |
| Master (outer) cases per pallet layer | 20 pc(s) |
| Total carbon footprint (kg of CO2e) | 10 |
| Pallet weight (imperial) | 139.8 kg (308.2 lbs) |
Logistics data
| Specification | Value |
|---|---|
| Pallet gross weight | 139.8 kg |
| Master (outer) cases per pallet | 100 pc(s) |
| UNSPSC-code | 43201409 |
Other features
| Specification | Value |
|---|---|
| Compatibility | HP EliteBook 6 G1i 13 inch Notebook AI PC; HP EliteBook 6 G1i 14 inch Notebook AI PC; HP EliteBook 6 G1i 16 inch Notebook AI PC; HP ProBook 4 G1i 14 inch Notebook AI PC;HP ProBook 4 G1i 16 inch Notebook AI PC; HP EliteBook 6 G1a 14 inch Notebook AI PC; HP EliteBook 6 G1a 16 inch Notebook AI PC; HP E |
