ASUS WL-138G V2

ASUS WL-138G V2

Model WL-138G V2Part no. 90-I9BOEI-OPAZ

29 specifications
  • Speed54 Mbit/s
  • ConnectivityWireless
  • TypePlug-in
  • InternalYes
  • TX power consumption350 mA
  • Compatible operating systemsWindows 98, ME, 2000, XP, Linux
See all specifications

Overview

Speed
54 Mbit/s
Connectivity
Wireless
Type
Plug-in
Internal
Yes
TX power consumption
350 mA
Compatible operating systems
Windows 98, ME, 2000, XP, Linux
Brand
ASUS
Category
Network Card
Model
WL-138G V2
Part numbers
90-I9BOEI-OPAZ, 90-I9B0E0-0XBZ
Also known as
ASUS WL-138G V2 Internal 54 Mbit/s

Specifications

29 specifications in 7 groups

Ports & interfaces

Connectivity technologyWireless
Host interfacePCI

Network

Maximum data transfer rate54 Mbit/s
Wi-Fi bandSingle-band (2.4 GHz)
Frequency range2.412 - 2.472 GHz
Spread spectrum methodDSSS
ModulationCCK, DBPSK, DQPSK, OFDM
Security algorithmsWPA

Design

InternalYes
Antenna connector typeRP-SMA
Form factorPlug-in
Plug and PlayYes
LED indicatorsYes
CertificationETS 300 328 & ETS 300 826, CE Mark; FCC 15C 15.247

Power

TX power consumption350 mA
RX power consumption290 mA

System requirements

Compatible operating systemsWindows 98, ME, 2000, XP, Linux

Weight & dimensions

Width40 mm
Depth122 mm
Height4.6 mm

Other features

Compliance industry standardsIEEE 802.11b/g
Channels quantity13 channels
Link/Act LEDYes
Supported data transfer rates1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps
Outdoor range802.11b - 310m, 802.11g - 60m
Indoor range802.11b - 40m, 802.11g - 30m
Bundled softwareMobile control center, Wireless setting, Mobile manager, Site survey, One Touch Setup Wizard
Slot type32-bit PCI
Output power description18dBm
