Allied Telesis 2914SX/LC Internal Fiber 1000 Mbit/s

Allied Telesis 2914SX/LC Internal Fiber 1000 Mbit/s

Model 2914SX/LCPart no. AT-2914SX/LC-901EAN 767035210636

30 specifications
  • Speed1000 Mbit/s
  • ConnectivityWired
  • Weight68 g
  • InternalYes
  • Power consumption (typical)1.5 W
  • Windows operating systems supportedWindows 10, Windows 7
See all specifications

Overview

Speed
1000 Mbit/s
Connectivity
Wired
Weight
68 g
Internal
Yes
Power consumption (typical)
1.5 W
Windows operating systems supported
Windows 10, Windows 7
Brand
Allied Telesis
Category
Network Card
Model
2914SX/LC
Part number
AT-2914SX/LC-901
EAN / UPC
767035210636
Also known as
Allied Telesis 2914SX/LC Internal Fiber 1000 Mbit/s

Specifications

30 specifications in 10 groups

Ports & interfaces

Connectivity technologyWired
Host interfacePCI Express
InterfaceFiber
Fiber optic connectorLC
Fiber ports quantity2

Network

Maximum data transfer rate1000 Mbit/s
Networking standardsIEEE 802.1Q, IEEE 802.1p, IEEE 802.2, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Security algorithmsSNMP
Wake-on-LAN readyYes
Auto-negotiationYes
Jumbo frames9600
Jumbo frames supportYes
Load balancing systemYes
Quality of Service (QoS) supportYes

Design

InternalYes
LED indicatorsYes
CertificationUL, FCC/EN55022 Class A, TUV, EN55024, CE, C-TICK, VCCI

Power

Power consumption (typical)1.5 W

System requirements

Windows operating systems supportedWindows 10, Windows 7
Linux operating systems supportedYes
Server operating systems supportedWindows Server 2016, Windows Server 2019

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-25 - 70 °C
Operating relative humidity (H-H)5 - 90%

Weight & dimensions

Width88 mm
Height69 mm
Weight68 g

Technical details

Compliance certificatesRoHS

Logistics data

Harmonized System (HS) code85176990

Other features

Flow control supportYes
