TerraMaster U8-412 NAS Intel® Core™ i3 i3-7100
TerraMaster

U8-412 NAS Intel® Core™ i3 i3-7100

8 GB DDR4 48 TB HDD Black

Model U8-412Part no. U8-412/48TB-IWEAN 6939236140331

148 specifications
  • ProcessorIntel® Core™ i3
  • Memory8 GB
  • TypeNAS
  • ColourBlack
  • Storage drives installedYes
  • Processor manufacturerIntel
See all specifications

Overview

Processor
Intel® Core™ i3
Memory
8 GB
Type
NAS
Colour
Black
Storage drives installed
Yes
Processor manufacturer
Intel
Brand
TerraMaster
Model
U8-412
Part numbers
U8-412/48TB-IW, U8-412/64TB-EXOS, U8-412/32TB-IW, U8-412/24TB-EXOS, U8-412/64TB-IWP, U8-412/96TB-IW +19 more
EAN / UPC
6939236140331
Also known as
TerraMaster U8-412 NAS Intel® Core™ i3 i3-7100 8 GB DDR4 48 TB HDD Black

Specifications

148 specifications in 15 groups

Storage

Storage drives installedYes
Total installed storage capacity48 TB
Number of storage drives installed8
Number of storage drives supported8
Installed storage drive typeHDD
Supported storage drive typesHDD & SSD
Storage drive capacity6 TB
Storage drive interfaceSerial ATA
Supported storage drive interfacesSerial ATA
Storage drive sizes supported2.5,3.5"
Maximum supported storage capacity108 TB
RAID supportYes
RAID levels0, 5, 6, 10, JBOD
Online RAID migrationYes
Online RAID expansionYes
Hot-swap drive baysYes
Supported file systemsBTRFS, FAT32, HFS+, NTFS, ext3, ext4

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i3
Processor generation7th gen Intel® Core™ i3
Processor modeli3-7100
Processor frequency3.9 GHz
Processor cores2
Processor threads4
Processor cache3 MB
Bus typeDMI3
CPU configuration (max)1
PCI Express configurations1x16, 1x8+2x4, 2x8
PCI Express slots version3.0
Processor cache typeSmart Cache
Processor codeSR35C
Processor codenameKaby Lake
Processor lithography14 nm
Processor operating modes64-bit
Processor package size37.5 x 37.5 mm
Processor socketLGA 1151 (Socket H4)
Scalability1S
SteppingS0
System bus rate8 GT/s
Thermal Design Power (TDP)51 W
Tjunction100 °C
On-board graphics card modelIntel® HD Graphics 630
Maximum internal memory supported by processor64 GB
Conflict-Free processorYes

Memory

Internal memory8 GB
Internal memory typeDDR4
Maximum RAM supported64 GB
Memory slots4

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Wi-FiNo
DHCP serverYes
iSCSI supportYes
Dynamic DNS (DDNS)Yes
Link aggregationYes
Supported network protocolsCIFS/SAMBA, NFS, FTP, TFTP, HTTPS, SSH, iSCSI, SMTP

Ports & interfaces

Ethernet LAN (RJ-45) ports4
USB portYes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Fiber ports quantity0
VGA (D-Sub) ports quantity1
HDMI ports quantity1
Serial ports quantity1
PCI Express x8 (Gen 3.x) slots3

Graphics

On-board graphics card DirectX version12.0
On-board graphics card ID0x5912
On-board graphics card OpenGL version4.4
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1100 MHz
Maximum on-board graphics card memory64 GB
Number of displays supported (on-board graphics)3

Design

Cooling typeActive
Product colourBlack
Number of fans3 fan(s)
Fan diameter8.3 cm
LED indicatorsHDD, LAN, Power

Performance

TypeNAS
Device classLarge Enterprise Business
Backup functionYes
Backup featuresCloud, USB drive, iSCSI LUN
Third-party supportYes
SnapshotYes
Management protocolsSNMP
Share folder access right managementYes
Access Control List (ACL)Yes
Browser supportedGoogle Chrome 48, Microsoft Internet Explorer 9, Mozilla Firefox 30, Apple Safari 4.5 +
Hot spareYes
Intel insideYes
On/off switchYes
Reset buttonYes
S.M.A.R.T. supportYes
Security algorithmsAES
Share folder512
System logYes
Universal Plug and Play (UPnP)Yes

Software

Windows operating systems supportedYes
Linux operating systems supportedYes
Mac operating systems supportedYes
Mobile operating systems supportedAndroid 5.0, iOS 8.2

Power

Power supply locationBuilt-in
Power supply unit (PSU) capacity550 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

Weight & dimensions

Width664 mm
Depth88 mm
Height440 mm
Package width575 mm
Package depth200 mm
Package height795 mm

Packaging content

Cables includedAC, LAN (RJ-45)
Quick installation guideYes

Processor special features

Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Enhanced Halt StateYes
Intel Identity Protection Technology version1.00
Intel Secure Key Technology version1.00
Intel Stable Image Platform Program (SIPP)No
Intel Stable Image Platform Program (SIPP) version0.00
Intel TSX-NINo
Intel TSX-NI version0.00
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® InTru™ 3D TechnologyYes
Intel® OS GuardYes
Intel® Quick Sync Video TechnologyYes
Intel® Secure KeyYes
Intel® Turbo Boost TechnologyNo
Maximum number of PCI Express lanes16
Thermal Monitoring TechnologiesYes
Thermal solution specificationPCG 2015C
Memory types supported by processorDDR3L-SDRAM, DDR4-SDRAM

Operational conditions

Operating temperature (T-T)5 - 40 °C
Operating relative humidity (H-H)5 - 95%
Storage temperature (T-T)-20 - 60 °C

Other features

Compliance certificatesRoHS
CertificationFCC, CE, CCC, KC, WEEE
Processor ARK ID97455
