F2-424 NAS/storage server Desktop Intel® N N95
8 GB DDR5 Black
Model F2-424EAN 6939236144636
86 specifications
- ProcessorIntel® N
- Memory8 GB
- Noise19 dB
- TypeNAS
- Weight2.2 kg
- ColourBlack
Overview
- Processor
- Intel® N
- Memory
- 8 GB
- Noise
- 19 dB
- Type
- NAS
- Weight
- 2.2 kg
- Colour
- Black
- Brand
- TerraMaster
- Category
- NAS & Storage Servers
- Model
- F2-424
- Part number
- F2-424
- EAN / UPC
- 6939236144636, 6939236144667
- Also known as
- TerraMaster F2-424 NAS/storage server Desktop Intel® N N95 8 GB DDR5 Black
Specifications
86 specifications in 14 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | No |
| Number of storage drives supported | 2 |
| Installed storage drive type | No |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | Serial ATA |
| Storage drive sizes supported | 2.5,3.5" |
| Maximum supported storage capacity | 44 TB |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Hot-swap drive bays | Yes |
| Supported file systems | BTRFS, FAT32, HFS+, NTFS, ext3, ext4 |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® N |
| Processor model | N95 |
| Processor boost frequency | 3.4 GHz |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor cache | 6 MB |
Memory
| Specification | Value |
|---|---|
| Internal memory | 8 GB |
| Internal memory type | DDR5 |
| Maximum RAM supported | 32 GB |
| ECC | No |
| Memory form factor | SO-DIMM |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000,2500 Mbit/s |
| iSCSI support | Yes |
| Wake-on-LAN ready | Yes |
| Dynamic DNS (DDNS) | Yes |
| Link aggregation | Yes |
| Supported network protocols | CIFS/SMB, NFS, FTP, SFTP, HTTPS, SSH, iSCSI, SNMP |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB port | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0b |
| Concurrent connections | 512 |
Design
| Specification | Value |
|---|---|
| Chassis type | Desktop |
| Cooling type | Active |
| Product colour | Black |
| Number of fans | 1 fan(s) |
| Fan diameter | 8 cm |
Performance
| Specification | Value |
|---|---|
| Type | NAS |
| Device class | Home & Home Office |
| Backup function | Yes |
| Backup features | Cloud, USB drive |
| Multilingual support | Yes |
| Number of users | 2048 user(s) |
| Noise level | 19 dB |
| Third-party support | Yes |
| Snapshot | Yes |
| Management protocols | SNMP |
| Access Control List (ACL) | Yes |
| Browser supported | Google Chrome, Mozilla Firefox, Apple Safari, Microsoft Edge |
| Hot spare | Yes |
| On/off switch | Yes |
| S.M.A.R.T. support | Yes |
| Security algorithms | AES, HTTPS, SNMP, SSH |
| Share folder | 512 |
| System log | Yes |
| Universal Plug and Play (UPnP) | Yes |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Other operating systems supported | Android, iOS |
Power
| Specification | Value |
|---|---|
| Power supply unit (PSU) capacity | 40 W |
| Power consumption (typical) | 22 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 119 mm |
| Depth | 154 mm |
| Height | 222 mm |
| Weight | 2.2 kg |
| Package width | 220 mm |
| Package depth | 170 mm |
| Package height | 258 mm |
Packaging content
| Specification | Value |
|---|---|
| External power adapter | Yes |
| Cables included | AC, LAN (RJ-45) |
| Quick installation guide | Yes |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 60 °C |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | CCC, CE, Federal Communications Commission (FCC), KC, RoHS, WEEE |
| Digital Living Network Alliance (DLNA) certified | Yes |
| Certification | FCC, CE, CCC, KC |
| Warranty period | 2 year(s) |
