TERRA NASBOX 2-2004

Model TERRA NASBOX 2-2004Part no. 1100969EAN 4039407040339

122 specifications

ProcessorIntel® Celeron®
Memory4 GB
TypeStorage server
OSLinux
Weight2.68 kg
ColourBlack

See all specifications

Overview

Processor: Intel® Celeron®
Memory: 4 GB
Type: Storage server
OS: Linux
Weight: 2.68 kg
Colour: Black

Brand: TERRA
Category: NAS & Storage Servers
Model: TERRA NASBOX 2-2004
Part number: 1100969
EAN / UPC: 4039407040339
Also known as: TERRA NASBOX 2-2004 Storage server Desktop Intel® Celeron® N3160 4 GB DDR3 4 TB HDD Linux Black

Specifications

122 specifications in 14 groups

Storage

Specification	Value
Storage drives installed	Yes
Total installed storage capacity	4 TB
Number of storage drives installed	2
Number of storage drives supported	2
Installed storage drive type	HDD
Supported storage drive types	HDD
Storage drive capacity	2 GB
Storage drive interface	Serial ATA
Storage drive size	2.5/3.5"
HDD speed	5400 RPM
Maximum supported storage capacity	20 TB
RAID support	Yes
RAID levels	0, 1
Hot-swap drive bays	Yes
Supported file systems	NTFS

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Celeron®
Processor model	N3160
Processor frequency	1.6 GHz
Processor boost frequency	2.24 GHz
Processor cores	4
Processor threads	4
Processor cache	2 MB
L2 cache	2 MB
CPU configuration (max)	1
ECC supported by processor	No
Integrated 4G WiMAX	No
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
PCI Express slots version	2.0
Processor cache type	L2
Processor code	SR2KP
Processor codename	Braswell
Processor lithography	14 nm
Processor operating modes	64-bit
Processor package size	25 x 27 mm
Processor series	Intel Celeron N3000 series
Processor socket	BGA 1170
Scenario Design Power (SDP)	4 W
Stepping	D1
Thermal Design Power (TDP)	6 W
Tjunction	90 °C
On-board graphics card model	Intel® HD Graphics 400
Maximum internal memory supported by processor	8 GB
Conflict-Free processor	Yes

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	DDR3

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	No
iSCSI support	Yes
Supported network protocols	TCP / IP (IPv4 & IPv6) / appletalk, SMB / CIFS, HTTP / HTTPS, FTP, FTP SSL / TLS, SFTP, NTP, TFTP, NFS v4, AFP, DHCP Client, DDNS, SSH, UPnP, Bonjour, WebDAV / WebDAV SSL, iSCSI, SNMP

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB port	Yes
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Fiber ports quantity	0
HDMI ports quantity	1

Graphics

Specification	Value
On-board graphics card DirectX version	12.0
On-board graphics card base frequency	320 MHz
On-board graphics card burst frequency	640 MHz
Maximum on-board graphics card memory	8 GB
Number of displays supported (on-board graphics)	3

Design

Specification	Value
Chassis type	Desktop
Cooling type	Active
Product colour	Black

Performance

Specification	Value
Type	Storage server
Device class	Home & Home Office

Software

Specification	Value
Operating system installed	Linux
Operating system version	Fedora

Power

Specification	Value
Power supply unit (PSU) capacity	48 W
Redundant power supply (RPS) support	No

Weight & dimensions

Specification	Value
Width	102 mm
Depth	213 mm
Height	146 mm
Weight	2.68 kg

Processor special features

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Enhanced Halt State	Yes
Intel Identity Protection Technology version	1.00
Intel Rapid Storage Technology	No
Intel Secure Boot	Yes
Intel Secure Boot Technology version	1.00
Intel Secure Key Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00
Intel Smart Connect Technology	No
Intel Smart Connect Technology version	0.00
Intel Smart Response Technology version	0.00
Intel Stable Image Platform Program (SIPP)	No
Intel Stable Image Platform Program (SIPP) version	0.00
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes
Intel® High Definition Audio (Intel® HD Audio)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® OS Guard	No
Intel® Quick Sync Video Technology	Yes
Intel® Secure Key	Yes
Intel® Small Business Advantage (Intel® SBA)	No
Intel® Smart Response Technology	No
Intel® Turbo Boost Technology	No
Intel® Wireless Display (Intel® WiDi)	Yes
Maximum number of PCI Express lanes	4
Number of execution units	12
Thermal Monitoring Technologies	Yes
UART	Yes
Memory channels supported by processor	Dual
Memory types supported by processor	DDR3L-SDRAM

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 75%

Other features

Specification	Value
Processor ARK ID	91831
