QNAP TVS-H1288X-W1250-16G NAS Tower Intel® Xeon® W-1250

16 GB DDR4 112 TB HDD Black

Model TVS-H1288X-W1250-16GPart no. TVS-H1288X-W1250-16G/96TB-REDPROEAN 5050914171650

114 specifications

Overview

Brand: QNAP
Category: NAS & Storage Servers
Model: TVS-H1288X-W1250-16G
Part numbers: TVS-H1288X-W1250-16G/96TB-REDPRO, TVS-H1288X-W1250-16G/80TB-IWP, TVS-H1288X-W1250-16G/112TB-IWP, TVS-H1288X-W1250-16G/128TB-IWP, TVS-H1288X-W1250-16G/16TB-IW, TVS-H1288X-W1250-16G/32TB-IW +8 more
EAN / UPC: 5050914171650, 5050914171667, 5050914171674, 5050914171681 +9 more
Also known as: QNAP TVS-H1288X-W1250-16G NAS Tower Intel® Xeon® W-1250 16 GB DDR4 112 TB HDD Black

114 specifications in 13 groups

Specification	Value
Storage drives installed	Yes
Total installed storage capacity	112 TB
Number of storage drives installed	12
Number of storage drives supported	12
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Storage drive interface	M.2, Serial ATA III
Supported storage drive interfaces	M.2, Serial ATA III
Storage drive sizes supported	2.5,3.5,M.2
Number of M.2 (M & B) slots	2
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, 50, 60, JBOD
Online RAID migration	Yes
Online RAID expansion	Yes
RAID rebuild	Yes
Hot-swap drive bays	Yes

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000,2500,10000 Mbit/s
Ethernet LAN data rate supported (max)	10000 Mbit/s
DHCP server	Yes
Jumbo frames support	Yes
iSCSI support	Yes
Wake-on-LAN ready	Yes
Dynamic DNS (DDNS)	Yes
Load balancing system	Yes

Specification	Value
Ethernet LAN (RJ-45) ports	6
USB port	Yes
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Fiber ports quantity	0
HDMI ports quantity	1
HDMI version	1.4b
3.5 mm (1/8-inch) out	Yes
Audio in/out	Yes
Microphone in	Yes
PCI Express x4 (Gen 3.x) slots	2
PCI Express x8 (Gen 3.x) slots	1

Specification	Value
Type	NAS
Backup function	Yes
Backup features	Cloud, USB drive, iSCSI LUN
Buzzer	Yes
Multilingual support	Yes
Noise level	26 dB
Third-party support	Yes
Access Control List (ACL)	Yes
Browser supported	Safari, Google Chrome, Internet Explorer, Mozilla Firefox
Built-in FTP server	Yes
Hot spare	Yes
On/off switch	Yes
Reset button	Yes
S.M.A.R.T. support	Yes
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
System log	Yes

Specification	Value
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Linux operating systems supported	Yes
Mac operating systems supported	Yes
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Other operating systems supported	Yes

Specification	Value
Power supply location	Built-in
Power supply unit (PSU) capacity	550 W
Power consumption (typical)	97.492 W
Power consumption (sleep)	85.216 W
AC input voltage	100 - 240 V
Fan voltage	12 V

Specification	Value
Cables included	AC, LAN (RJ-45)
Number of screws	48

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Storage temperature (T-T)	-20 - 70 °C
