TVS-672XT NAS Tower Intel® Core™ i3

8 GB DDR4 0 TB QNAP QTS Black

Model TVS-672XTPart no. TVS-672XT-I3-8G/18TB-IWEAN 5050914113322

114 specifications

Overview

Brand: QNAP
Category: NAS & Storage Servers
Model: TVS-672XT
Part numbers: TVS-672XT-I3-8G/18TB-IW, TVS-672XT-I3-8G, TVS-672XT-I3-8G-US, TVS-672XT-I3-8G-12TB-IWP, TVS-672XT-I3-8G-48TB-EXOS, TVS-672XT-I3-8G-72TB-IW +34 more
EAN / UPC: 5050914113322, 4713213514535, 885022016488, 5050914113216 +39 more
Also known as: QNAP TVS-672XT NAS Tower Intel® Core™ i3 8 GB DDR4 0 TB QNAP QTS Black

114 specifications in 13 groups

Specification	Value
Storage drives installed	No
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	6
Installed storage drive type	No
Supported storage drive types	HDD & SSD
Storage drive capacity	0 GB
Supported storage drive interfaces	M.2, Serial ATA II, Serial ATA III
Storage drive sizes supported	2.5,3.5,M.2
Number of M.2 (M & B) slots	2
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, 50, JBOD
Online RAID migration	Yes
Online RAID expansion	Yes
Hot-swap drive bays	Yes
Supported file systems	FAT32, HFS+, NTFS, exFAT, ext3, ext4
Auto-rebuild	Yes
Bad block scan	Yes
Disk roaming	Yes

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000,2500,5000,10000 Mbit/s
Ethernet LAN data rate supported (max)	10000 Mbit/s
DHCP client	Yes
DHCP server	Yes
Jumbo frames support	Yes
iSCSI support	Yes
Wake-on-LAN ready	Yes
Dynamic DNS (DDNS)	Yes
Link aggregation	Yes
Load balancing system	Yes
Supported network protocols	TCP/IP, IPv4, IPv6
WLAN adapter supported	Yes

Specification	Value
Ethernet LAN (RJ-45) ports	3
USB port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
HDMI ports quantity	1
HDMI version	2.0
Thunderbolt 3 ports quantity	2
Concurrent connections	2500
PCI Express x4 (Gen 3.x) slots	1
PCI Express x16 (Gen 3.x) slots	1

Specification	Value
Type	NAS
Device class	Home & Home Office
Backup function	Yes
Backup features	iSCSI LUN
Buzzer	Yes
Multilingual support	Yes
Noise level	23.8 dB
Snapshot	Yes
Management protocols	SNMP 2/3
Share folder access right management	Yes
Web-based management	Yes
Access Control List (ACL)	Yes
Browser supported	Apple Safari, Google Chrome, Microsoft Internet Explorer, Mozilla Firefox
Built-in FTP server	Yes
Built-in iTunes server	Yes
Hot spare	Yes
On/off switch	Yes
Remotely operated	Yes
Reset button	Yes
S.M.A.R.T. support	Yes
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SSH
Share folder	CIFS/SMB
System log	Yes
USB copy function	Yes
Universal Plug and Play (UPnP)	Yes

Specification	Value
Operating system installed	QNAP QTS
Operating system version	5.0.0
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterpri
Linux operating systems supported	CentOS 7.0, SuSE Linux 12.0, SuSE Linux 12.3, SuSE Linux 15, Ubuntu 14.04, Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, Ubuntu 16.04, Ubuntu 16.10, Ubuntu 17.10, Ubuntu 18.04 LTS, Ubuntu 20.04 LTS
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Other operating systems supported	IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 11

Specification	Value
Power supply unit (PSU) capacity	250 W
Power consumption (typical)	45.6 W
Power consumption (HDD standby)	26.52 W
AC input voltage	100 - 240 V
Fan voltage	12 V
