QNAP TS-659 Pro II 6TB

Model TS-659 Pro II 6TBPart no. TS-659 PRO II 6TB

87 specifications

Overview

87 specifications in 12 groups

Specification	Value
Total installed storage capacity	6 TB
Number of storage drives supported	6
Storage drive size	2.5/3.5"
Maximum supported storage capacity	6 TB
RAID levels	0, 1, 5, 6, 10
Supported file systems	ext3, ext4, FAT32, HFS+, NTFS

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	D525
Processor frequency	1.8 GHz
Processor cores	2
Processor threads	4
Processor cache	1 MB
L2 cache	1 MB
Bus type	DMI
ECC supported by processor	No
Number of processors installed	1
Physical Address Extension (PAE)	32 bit
Processing Die size	87 mm²
Processor cache type	L2
Processor code	SLBXC
Processor codename	Pineview
Processor lithography	45 nm
Processor operating modes	64-bit
Processor package size	22 x 22 mm
Processor socket	BGA 559
Stepping	B0
Thermal Design Power (TDP)	13 W
Tjunction	100 °C
Maximum internal memory supported by processor	4 GB
Memory bandwidth supported by processor (max)	6.4 GB/s
Conflict-Free processor	No

Specification	Value
DHCP client	Yes
DHCP server	Yes
Jumbo frames support	Yes
iSCSI support	Yes
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	TCP/IP

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
VGA (D-Sub) ports quantity	1
eSATA ports quantity	2

Specification	Value
Buzzer	Yes
Noise level	35.7 dB
Management protocols	CIFS, SMB, AFP (3.1), NFS, FTP, HTTP, HTTPS, Telnet, SSH, iSCSI, SNMP
Web-based management	Yes
Access Control List (ACL)	Yes
On/off switch	Yes
Security algorithms	HTTPS, SSH

Specification	Value
Power supply unit (PSU) capacity	250 W
Power consumption (typical)	43 W
Power consumption (sleep)	22 W

Specification	Value
Weight	5.2 kg

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	No
Execute Disable Bit	Yes
Idle States	No
Intel 64	Yes
Intel Demand Based Switching	No
Intel Enhanced Halt State	No
Intel Trusted Execution Technology	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	No
Number of Processing Die Transistors	176 M
Thermal Monitoring Technologies	No
Memory channels supported by processor	Single

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95%

Specification	Value
Compatible operating systems	Windows 2000 (32/64bit) XP (32/64bit) Vista (32/64bit) 7 (32/64bit) Windows Server 2003 2008 Mac OS X Linux Unix
Dimensions (WxDxH)	175 x 257 x 235 mm
Fan	90 mm
Minimum system requirements	Internet Explorer 7/8 Firefox 3 Safari 3/4 Google Chrome
Networking features	Gigabit Ethernet
Power LED	Yes
Power requirements	100-240V, 50/60Hz
Processor ARK ID	49490
Connectivity LEDs	Yes
