QNAP TS-659 PRO II

Model TS-659 PRO IIEAN 885022001651

106 specifications

Overview

Brand: QNAP
Category: NAS & Storage Servers
Model: TS-659 PRO II
Part number: TS-659 PRO II
EAN / UPC: 885022001651, 4712511121698, 5050914640248, 5711045398575
Also known as: QNAP TS-659 PRO II NAS/storage server Tower Intel Atom® D525 1 GB DDR3 0 TB Black

106 specifications in 12 groups

Specification	Value
Storage drives installed	No
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	6
Supported storage drive types	HDD
Storage drive interface	Serial ATA II, Serial ATA III
Storage drive size	2.5/3.5"
Maximum supported storage capacity	18 TB
RAID support	Yes
RAID levels	0, 1, 5, 6, 10
Hot-swap drive bays	Yes
Supported file systems	ext3, ext4, FAT32, HFS+, NTFS

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	D525
Processor frequency	1.8 GHz
Processor cores	2
Processor threads	4
Processor cache	1 MB
L2 cache	1 MB
Bus type	DMI
ECC supported by processor	No
Physical Address Extension (PAE)	32 bit
Processing Die size	87 mm²
Processor cache type	L2
Processor code	SLBXC
Processor codename	Pineview
Processor lithography	45 nm
Processor operating modes	64-bit
Processor package size	22 x 22 mm
Processor socket	BGA 559
Stepping	B0
Thermal Design Power (TDP)	13 W
Tjunction	100 °C
Maximum internal memory supported by processor	4 GB
Memory bandwidth supported by processor (max)	6.4 GB/s
Conflict-Free processor	No

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	No
DHCP client	Yes
DHCP server	Yes
Jumbo frames support	Yes
iSCSI support	Yes
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	TCP/IP

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Fiber ports quantity	0
eSATA ports quantity	2

Specification	Value
Type	NAS
Backup function	Yes
Buzzer	Yes
Noise level	35.7 dB
Management protocols	CIFS, SMB, AFP (3.1), NFS, FTP, HTTP, HTTPS, Telnet, SSH, iSCSI, SNMP
Web-based management	Yes
Access Control List (ACL)	Yes
On/off switch	Yes
Reset button	Yes
Security algorithms	HTTPS, SSH

Specification	Value
Power supply unit (PSU) capacity	250 W
Power consumption (typical)	43 W
Power consumption (sleep)	22 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	No
Execute Disable Bit	Yes
Idle States	No
Intel 64	Yes
Intel Demand Based Switching	No
Intel Enhanced Halt State	No
Intel Trusted Execution Technology	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	No
Number of Processing Die Transistors	176 M
Thermal Monitoring Technologies	No
Memory channels supported by processor	Single

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95%

Specification	Value
Minimum system requirements	Internet Explorer 7/8 Firefox 3 Safari 3/4 Google Chrome
Networking features	Gigabit Ethernet
Power LED	Yes
Processor ARK ID	49490
Connectivity LEDs	Yes
