TS-569PRO NAS Tower Intel Atom®
1 GB DDR3 20 TB HDD Linux Black
Model TS-569PROPart no. TS-569PRO/5TB-RED
73 specifications
- ProcessorIntel Atom®
- Memory1 GB
- Noise21.43 dB
- TypeNAS
- OSLinux
- ColourBlack
Overview
- Processor
- Intel Atom®
- Memory
- 1 GB
- Noise
- 21.43 dB
- Type
- NAS
- OS
- Linux
- Colour
- Black
- Brand
- QNAP
- Category
- NAS & Storage Servers
- Model
- TS-569PRO
- Part numbers
- TS-569PRO/5TB-RED, TS-569PRO-20TB-SE, TS-569PRO-10TB-RE, TS-569PRO-10TB-TS, TS-569PRO-15TB-RE, TS-569PRO-15TB-SE +16 more
- Also known as
- QNAP TS-569PRO NAS Tower Intel Atom® 1 GB DDR3 20 TB HDD Linux Black
Specifications
73 specifications in 12 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | Yes |
| Total installed storage capacity | 20 TB |
| Number of storage drives installed | 5 |
| Number of storage drives supported | 5 |
| Installed storage drive type | HDD |
| Supported storage drive types | HDD & SSD |
| Storage drive interface | Serial ATA II, Serial ATA III |
| Storage drive size | 2.5/3.5" |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Hot-swap drive bays | Yes |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Atom® |
| Processor frequency | 2.13 GHz |
| Processor cores | 2 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 1 GB |
| Internal memory type | DDR3 |
| Maximum RAM supported | 3 GB |
| Flash memory | 512 MB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| DHCP client | Yes |
| DHCP server | Yes |
| Jumbo frames support | Yes |
| iSCSI support | Yes |
| Wake-on-LAN ready | Yes |
| Supported network protocols | CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, SMSC |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 5 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Fiber ports quantity | 0 |
| VGA (D-Sub) ports quantity | 1 |
| eSATA ports quantity | 2 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Cooling type | Active |
| Product colour | Black |
| Number of fans | 1 fan(s) |
| Fan diameter | 12 cm |
| LED indicators | eSATA, HDD, LAN, Power, Status, USB |
| Built-in display | Yes |
| Display type | LCD |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Performance
| Specification | Value |
|---|---|
| Type | NAS |
| Device class | Small & Medium Business |
| Backup function | Yes |
| Buzzer | Yes |
| Multilingual support | Yes |
| Number of users | 4096 user(s) |
| Noise level | 21.43 dB |
| Noise level (idle) | 14.7 dB |
| On/off switch | Yes |
| Reset button | Yes |
| Security algorithms | HTTPS, SSH, SSL/TLS |
Software
| Specification | Value |
|---|---|
| Operating system installed | Linux |
| Windows operating systems supported | Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Win |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2 |
| Other operating systems supported | Android |
Power
| Specification | Value |
|---|---|
| Power supply location | Built-in |
| Power supply unit (PSU) capacity | 250 W |
| Number of power supply units | 1 |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Fan voltage | 12 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 210.6 mm |
| Depth | 235.4 mm |
| Height | 185 mm |
Packaging content
| Specification | Value |
|---|---|
| External power adapter | No |
| Cables included | AC, LAN (RJ-45) |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
