QNAP TS-569 PRO, 5x 2 TB

QNAP TS-569 PRO, 5x 2 TB

Model TS-569 PRO, 5x 2 TBPart no. TS-569 PRO/5X2,0TBEAN 4050487672227

59 specifications
  • ProcessorIntel Atom®
  • Memory1 GB
  • Noise35 dB
  • OSLinux
  • Weight5.1 kg
  • ColourBlack
See all specifications

Overview

Processor
Intel Atom®
Memory
1 GB
Noise
35 dB
OS
Linux
Weight
5.1 kg
Colour
Black
Brand
QNAP
Model
TS-569 PRO, 5x 2 TB
Part number
TS-569 PRO/5X2,0TB
EAN / UPC
4050487672227
Also known as
QNAP TS-569 PRO, 5x 2 TB Tower Intel Atom® 1 GB DDR2 10 TB Linux Black

Specifications

59 specifications in 13 groups

Storage

Total installed storage capacity10 TB
Number of storage drives installed5
Number of storage drives supported5
Storage drive capacity2 TB
Storage drive interfaceSerial ATA
Storage drive size2.5/3.5"
RAID levels0, 1, 5, 6, 10, JBOD
Hot-swap drive baysYes
Supported file systemsext3, ext4, FAT32, HFS+, NTFS

Processor

Processor familyIntel Atom®
Processor frequency2.13 GHz
Number of processors installed1

Memory

Internal memory1 GB
Internal memory typeDDR2
Maximum RAM supported3 GB
Flash memory512 MB

Network

DHCP clientYes
DHCP serverYes
Jumbo frames supportYes
iSCSI supportYes
Wake-on-LAN readyYes
Compliance industry standardsIEEE 802.3, 802.3u, 802.3ab
Cabling technology10/100/1000Base-T(X)
Supported network protocolsCIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, SMSC, UPnP

Ports & interfaces

Ethernet LAN (RJ-45) ports2
USB 2.0 ports quantity5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
VGA (D-Sub) ports quantity1
eSATA ports quantity2
eSATAYes

Design

Chassis typeTower
Product colourBlack
Number of fans1 fan(s)
LED indicatorsLAN, Status, USB
Display typeLCD
Cable lock slotYes

Performance

Multilingual supportYes
Noise level35 dB
Noise level (idle)34.3 dB
Management protocolsCIFS/SMB, AFP, FTP
Web-based managementYes
On/off switchYes
Reset buttonYes
Security algorithms256-bit AES, 802.1x RADIUS, HTTPS, SSH, SSL/TLS

Software

Operating system installedLinux

Power

Power supply unit (PSU) capacity250 W
Power consumption (typical)48.5 W
Power consumption (sleep)29.1 W
Output power1 W

Weight & dimensions

Weight5.1 kg

Packaging content

Cables includedAC, LAN (RJ-45)

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 95%

Other features

Compatible operating systems- Windows XP, Vista, Windows 7 (32/64-bit), Windows Server 2003/2008 R2 - Apple Mac OS X - Linux & UNIX
Dimensions (WxDxH)210.6 x 235.4 x 185 mm
Fan12 cm, 12V DC
Networking featuresGigabit Ethernet
Power LEDYes
Power requirements100-240V AC, 50/60Hz
