QNAP TS-531X NAS Desktop Annapurna Labs AL314

8 GB DDR3 0 TB QNAP Turbo System Black

Model TS-531XPart no. TS-531X-2G-10TB-SEAEAN 5050914987633

88 specifications

Overview

Brand: QNAP
Category: NAS & Storage Servers
Model: TS-531X
Part numbers: TS-531X-2G-10TB-SEA, TS-531X-8G, TS-531X-2G, TS-531X-2G + 5X ST1000VN002, TS-531X-2G + 5X ST2000VN0001, TS-531X-2G-10TB-SEAEN +34 more
EAN / UPC: 5050914987633, 4058154139110, 4712511128482, 4713213510353 +56 more
Also known as: QNAP TS-531X NAS Desktop Annapurna Labs AL314 8 GB DDR3 0 TB QNAP Turbo System Black

88 specifications in 13 groups

Specification	Value
Storage drives installed	No
Total installed storage capacity	0 TB
Number of storage drives supported	5
Installed storage drive type	No
Supported storage drive types	HDD & SSD
Storage drive capacity	0 GB
Storage drive interface	Serial ATA III
Storage drive size	2.5/3.5"
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, JBOD
Hot-swap drive bays	Yes
Supported file systems	FAT32, HFS+, NTFS, ext3, ext4

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000,10000 Mbit/s
Wi-Fi	No
DHCP client	Yes
DHCP server	Yes
Jumbo frames support	Yes
iSCSI support	Yes
Wake-on-LAN ready	Yes
Supported network protocols	IPv4, IPv6, CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, SMSC

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB port	Yes
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Fiber ports quantity	2
Fiber optic connector	SFP+

Specification	Value
Type	NAS
Device class	Small & Medium Business
Backup function	Yes
Backup features	Cloud, iSCSI LUN
Multilingual support	Yes
Noise level	22.4 dB
Web-based management	Yes
Access Control List (ACL)	Yes
Browser supported	Internet Explorer 10+, Firefox 8+, Safari 4+, Chrome
Built-in FTP server	Yes
Built-in iTunes server	Yes
Hot spare	Yes
On/off switch	Yes
Reset button	Yes
S.M.A.R.T. support	Yes
Security algorithms	256-bit AES, HTTPS, SNMP, SSH, SSL/TLS
Share folder	CIFS/SMB
System log	Yes

Specification	Value
Operating system installed	QNAP Turbo System
Operating system version	4.2
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win
Linux operating systems supported	Yes
Mac operating systems supported	Yes
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2

Specification	Value
Power supply location	Built-in
Power supply unit (PSU) capacity	240 W
Number of power supply units	1
Power consumption (typical)	29.31 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Fan voltage	12 V
Output current	3.5 A

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%

Specification	Value
Digital Living Network Alliance (DLNA) certified	Yes
Power management	Yes
