TS-253BE-2G NAS Tower Intel® Celeron® J3455
2 GB DDR3L 4 TB HDD QNAP Turbo System Black, Blue
Model TS-253BE-2GPart no. TS-253BE-2G/4TB-IWEAN 5055628427000
172 specifications
- ProcessorIntel® Celeron®
- Memory2 GB
- Noise16.7 dB
- TypeNAS
- OSQNAP Turbo System
- Weight1.66 kg
Overview
- Processor
- Intel® Celeron®
- Memory
- 2 GB
- Noise
- 16.7 dB
- Type
- NAS
- OS
- QNAP Turbo System
- Weight
- 1.66 kg
- Brand
- QNAP
- Category
- NAS & Storage Servers
- Model
- TS-253BE-2G
- Part number
- TS-253BE-2G/4TB-IW
- EAN / UPC
- 5055628427000
- Also known as
- QNAP TS-253BE-2G NAS Tower Intel® Celeron® J3455 2 GB DDR3L 4 TB HDD QNAP Turbo System Black, Blue
Specifications
172 specifications in 15 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | Yes |
| Total installed storage capacity | 4 TB |
| Number of storage drives installed | 2 |
| Number of storage drives supported | 2 |
| Installed storage drive type | HDD |
| Supported storage drive types | HDD & SSD |
| Storage drive capacity | 2 TB |
| Storage drive interface | Serial ATA III |
| Supported storage drive interfaces | Serial ATA III |
| Storage drive sizes supported | 2.5,3.5" |
| RAID support | Yes |
| RAID levels | 0, 1, 5+S, 5, 6, 10, JBOD |
| Hot-swap drive bays | Yes |
| Supported file systems | FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Celeron® |
| Processor model | J3455 |
| Processor frequency | 1.5 GHz |
| Processor boost frequency | 2.3 GHz |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor cache | 2 MB |
| CPU configuration (max) | 1 |
| ECC supported by processor | No |
| PCI Express configurations | 1x2+2x1, 4x1 |
| PCI Express slots version | 2.0 |
| Processor cache type | Smart Cache |
| Processor code | SR2Z9 |
| Processor codename | Apollo Lake |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor package size | 24 x 31 mm |
| Processor socket | BGA 1296 |
| Stepping | B1 |
| Thermal Design Power (TDP) | 10 W |
| Tjunction | 105 °C |
| On-board graphics card model | Intel® HD Graphics 500 |
| Maximum internal memory supported by processor | 8 GB |
| Conflict-Free processor | Yes |
Memory
| Specification | Value |
|---|---|
| Internal memory | 2 GB |
| Internal memory type | DDR3L |
| Memory clock speed | 1866 MHz |
| Maximum RAM supported | 8 GB |
| Memory form factor | SO-DIMM |
| Memory slots | 2 |
| Flash memory | 512 MB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | No |
| DHCP client | Yes |
| DHCP server | Yes |
| Jumbo frames support | Yes |
| iSCSI support | Yes |
| Wake-on-LAN ready | Yes |
| Dynamic DNS (DDNS) | Yes |
| Link aggregation | Yes |
| Supported network protocols | IPv4/v6, STP, FTP, CIFS/SMB, AFP, FXP, PPTP |
| WLAN adapter supported | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB port | Yes |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| Fiber ports quantity | 0 |
| HDMI ports quantity | 2 |
| 3.5 mm (1/8-inch) out | Yes |
| Audio in/out | Yes |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card base frequency | 250 MHz |
| On-board graphics card burst frequency | 750 MHz |
| On-board graphics card dynamic frequency (max) | 750 MHz |
| Maximum on-board graphics card memory | 8 GB |
| Number of displays supported (on-board graphics) | 3 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Cooling type | Active |
| Product colour | Black, Blue |
| Number of fans | 1 fan(s) |
| Fan diameter | 12 cm |
| LED indicators | HDD, LAN, Power, Status, USB |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Performance
| Specification | Value |
|---|---|
| Type | NAS |
| Device class | Small & Medium Business |
| Backup function | Yes |
| Backup features | Cloud, USB drive, iSCSI LUN |
| Number of users | 4096 user(s) |
| Noise level | 16.7 dB |
| Third-party support | Yes |
| Snapshot | Yes |
| Management protocols | SNMP |
| Share folder access right management | Yes |
| Web-based management | Yes |
| Backup button | Yes |
| Browser supported | Apple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox |
| Built-in BitTorrent client | Yes |
| Built-in FTP server | Yes |
| Built-in iTunes server | Yes |
| Hot spare | Yes |
| On/off switch | Yes |
| Remotely operated | Yes |
| Reset button | Yes |
| Security algorithms | 256-bit AES, FIPS 140-2, HTTPS, SSH |
| Share folder | 512 |
| System log | Yes |
| USB copy function | Yes |
| Universal Plug and Play (UPnP) | Yes |
Software
| Specification | Value |
|---|---|
| Operating system installed | QNAP Turbo System |
| Operating system version | 4.3.4 |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 |
Power
| Specification | Value |
|---|---|
| Power supply location | External |
| Power supply unit (PSU) capacity | 65 W |
| Number of power supply units | 1 |
| Power consumption (typical) | 20.42 W |
| Power consumption (sleep) | 13.07 W |
| AC input voltage | 100 - 240 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 105 mm |
| Depth | 226 mm |
| Height | 168 mm |
| Weight | 1.66 kg |
| Package weight | 2.76 kg |
Packaging content
| Specification | Value |
|---|---|
| External power adapter | Yes |
| Cables included | AC, LAN (RJ-45) |
| Quick installation guide | Yes |
| Number of screws | 6 |
Processor special features
| Specification | Value |
|---|---|
| Embedded options available | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Rapid Storage Technology | No |
| Intel Secure Boot | Yes |
| Intel Secure Boot Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Small Business Advantage (SBA) version | 0.00 |
| Intel Smart Connect Technology | No |
| Intel Smart Connect Technology version | 0.00 |
| Intel Smart Response Technology version | 0.00 |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® OS Guard | No |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Secure Key | Yes |
| Intel® Small Business Advantage (Intel® SBA) | No |
| Intel® Smart Response Technology | No |
| Intel® Turbo Boost Technology | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Maximum number of PCI Express lanes | 6 |
| Number of execution units | 12 |
| Thermal Monitoring Technologies | Yes |
| UART | Yes |
| Memory channels supported by processor | Dual |
| Memory types supported by processor | DDR3L, LPDDR3-SDRAM, LPDDR4-SDRAM |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Other features
| Specification | Value |
|---|---|
| Processor ARK ID | 95594 |
