QNAP TS-251A NAS Tower Intel® Celeron® N3060
QNAP

TS-251A NAS Tower Intel® Celeron® N3060

2 GB DDR3L 0 TB QNAP Turbo System Green, White

Model TS-251APart no. TS-251A-2G/STG10TBEAN 5050914962746

172 specifications
  • ProcessorIntel® Celeron®
  • Memory2 GB
  • Noise18.3 dB
  • TypeNAS
  • OSQNAP Turbo System
  • Weight1.28 kg
See all specifications

Overview

Processor
Intel® Celeron®
Memory
2 GB
Noise
18.3 dB
Type
NAS
OS
QNAP Turbo System
Weight
1.28 kg
Brand
QNAP
Model
TS-251A
Part numbers
TS-251A-2G/STG10TB, TS-251A-2G, TS-251A-4G, TS-251A-2G-US, TS-251A-4G-US, TS-251A-4G/STG10TB +34 more
EAN / UPC
5050914962746, 4058154118030, 4712511129472, 4058154117811 +56 more
Also known as
QNAP TS-251A NAS Tower Intel® Celeron® N3060 2 GB DDR3L 0 TB QNAP Turbo System Green, White

Specifications

172 specifications in 16 groups

Storage

Storage drives installedNo
Total installed storage capacity0 TB
Number of storage drives installed0
Number of storage drives supported2
Installed storage drive typeNo
Supported storage drive typesHDD & SSD
Storage drive capacity0 GB
Supported storage drive interfacesSerial ATA III
Storage drive sizes supported2.5,3.5"
RAID supportYes
RAID levels0, 1, JBOD
Hot-swap drive baysYes
Supported file systemsFAT32, HFS+, NTFS, ext3, ext4

Processor

Processor manufacturerIntel
Processor familyIntel® Celeron®
Processor modelN3060
Processor frequency1.6 GHz
Processor boost frequency2.48 GHz
Processor cores2
Processor threads2
Processor cache2 MB
CPU configuration (max)1
ECC supported by processorNo
Integrated 4G WiMAXNo
PCI Express configurations1x2+2x1, 1x4, 2x2, 4x1
PCI Express slots version2.0
Processor cache typeL2
Processor codeSR2KN
Processor codenameBraswell
Processor lithography14 nm
Processor operating modes64-bit
Processor package size25 x 27 mm
Processor seriesIntel Celeron N3000 series
Processor socketBGA 1170
Scenario Design Power (SDP)4 W
SteppingD1
System bus rate5 GT/s
Thermal Design Power (TDP)6 W
Tjunction90 °C
On-board graphics card modelIntel® HD Graphics 400
Maximum internal memory supported by processor8 GB
Conflict-Free processorYes

Memory

Internal memory2 GB
Internal memory typeDDR3L
Maximum RAM supported8 GB
Memory form factorSO-DIMM
Memory slots2
Flash memory4096 MB

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Wi-FiNo
DHCP clientYes
DHCP serverYes
Jumbo frames supportYes
iSCSI supportYes
Wake-on-LAN readyYes
Link aggregationYes
Supported network protocolsCIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC

Ports & interfaces

Ethernet LAN (RJ-45) ports2
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Fiber ports quantity0
HDMI ports quantity1

Graphics

On-board graphics card DirectX version12.0
On-board graphics card base frequency320 MHz
On-board graphics card burst frequency600 MHz
Maximum on-board graphics card memory8 GB
Number of displays supported (on-board graphics)3

Design

Chassis typeTower
Cooling typeActive
Product colourGreen, White
Number of fans1 fan(s)
Fan diameter7 cm
LED indicatorsPower, Ready, Reset
Cable lock slotYes
Cable lock slot typeKensington

Performance

TypeNAS
Device classHome & Home Office
Backup functionYes
Backup featuresCloud, iSCSI LUN
Multilingual supportYes
Noise level18.3 dB
Card reader integratedYes
Compatible memory cardsSD
Share folder access right managementYes
Web-based managementYes
Access Control List (ACL)Yes
Browser supportedMicrosoft Internet Explorer 10+, Mozilla Firefox 8+, Apple Safari 4+, Google Chrome
Built-in FTP serverYes
Built-in UPnP AV media serverYes
Built-in iTunes serverYes
Hot spareYes
On/off switchYes
Reset buttonYes
S.M.A.R.T. supportYes
Security algorithms256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
Share folderCIFS/SMB
System logYes

Software

Operating system installedQNAP Turbo System
Operating system version4.2
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows
Linux operating systems supportedYes
Mac operating systems supportedMac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.2 Jaguar, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2

Power

Power supply locationExternal
Power supply unit (PSU) capacity65 W
Number of power supply units1
Power consumption (typical)16.2 W
Power consumption (sleep)7.9 W
Power consumption (off)0.72 W
AC input voltage100-240 V
Fan voltage12 V

Weight & dimensions

Width102 mm
Depth219 mm
Height169 mm
Weight1.28 kg
Package weight2.64 kg

Packaging content

External power adapterYes
Cables includedAC, LAN (RJ-45)
Quick installation guideYes
Number of screws14

Processor special features

Embedded options availableYes
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Home Networking (by Intel)Yes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Enhanced Halt StateYes
Intel Identity Protection Technology version1.00
Intel Rapid Storage TechnologyNo
Intel Secure BootYes
Intel Secure Boot Technology version1.00
Intel Secure Key Technology version1.00
Intel Small Business Advantage (SBA) version0.00
Intel Smart Connect TechnologyNo
Intel Smart Connect Technology version0.00
Intel Smart Response Technology version0.00
Intel Stable Image Platform Program (SIPP)No
Intel Stable Image Platform Program (SIPP) version0.00
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)No
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Anti-Theft Technology (Intel® AT)No
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Yes
Intel® High Definition Audio (Intel® HD Audio)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)No
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® InTru™ 3D TechnologyNo
Intel® Insider™No
Intel® OS GuardNo
Intel® Quick Sync Video TechnologyYes
Intel® Secure KeyYes
Intel® Small Business Advantage (Intel® SBA)No
Intel® Smart Response TechnologyNo
Intel® Turbo Boost TechnologyNo
Intel® Wireless Display (Intel® WiDi)Yes
Maximum number of PCI Express lanes4
Number of execution units12
Thermal Monitoring TechnologiesYes
UARTYes
Memory channels supported by processorDual
Memory types supported by processorDDR3L-SDRAM

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95%

Logistics data

Harmonized System (HS) code84714100

Other features

Digital Living Network Alliance (DLNA) certifiedYes
Power managementYes
Processor ARK ID91832
