TS-231P2 NAS Tower Annapurna Labs AL314
4 GB DDR3 0 TB QNAP Turbo System White
Model TS-231P2Part no. TS-231P2-1G/20TB-IWEAN 5051868076251
71 specifications
- ProcessorAnnapurna Labs
- Memory4 GB
- Noise19.2 dB
- TypeNAS
- OSQNAP Turbo System
- Weight1.28 kg
Overview
- Processor
- Annapurna Labs
- Memory
- 4 GB
- Noise
- 19.2 dB
- Type
- NAS
- OS
- QNAP Turbo System
- Weight
- 1.28 kg
- Brand
- QNAP
- Category
- NAS & Storage Servers
- Model
- TS-231P2
- Part numbers
- TS-231P2-1G/20TB-IW, TS-231P2-4G, TS-231P2-1G, TS-231P2-1G-US, TS-231P2-4G-US, TS-231P2-4G_2TB +34 more
- EAN / UPC
- 5051868076251, 885022013708, 4058154236307, 4713213511770 +42 more
- Also known as
- QNAP TS-231P2 NAS Tower Annapurna Labs AL314 4 GB DDR3 0 TB QNAP Turbo System White
Specifications
71 specifications in 12 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | No |
| Total installed storage capacity | 0 TB |
| Number of storage drives installed | 0 |
| Number of storage drives supported | 2 |
| Installed storage drive type | No |
| Supported storage drive types | HDD & SSD |
| Storage drive capacity | 0 GB |
| Supported storage drive interfaces | Serial ATA, Serial ATA II, Serial ATA III |
| RAID support | Yes |
| RAID levels | 0, 1, JBOD |
| Hot-swap drive bays | Yes |
| Supported file systems | FAT32, HFS+, NTFS, ext3, ext4 |
Processor
| Specification | Value |
|---|---|
| Processor family | Annapurna Labs |
| Processor model | AL314 |
| Processor frequency | 1.7 GHz |
| Processor cores | 4 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Internal memory type | DDR3 |
| Memory form factor | SO-DIMM |
| Memory slots | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | No |
| DHCP client | Yes |
| DHCP server | Yes |
| Jumbo frames support | Yes |
| iSCSI support | Yes |
| Wake-on-LAN ready | Yes |
| Dynamic IP | Yes |
| Link aggregation | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB port | Yes |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Fiber ports quantity | 0 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Cooling type | Active |
| Product colour | White |
| Number of fans | 1 fan(s) |
| Fan diameter | 7 cm |
| LED indicators | Yes |
| Built-in display | No |
| Cable lock slot | Yes |
Performance
| Specification | Value |
|---|---|
| Type | NAS |
| Device class | Home & Home Office |
| Backup function | Yes |
| Backup features | Cloud, iSCSI LUN |
| Buzzer | Yes |
| Noise level | 19.2 dB |
| Browser supported | Chrome, Firefox |
| Built-in FTP server | Yes |
| Built-in UPnP AV media server | Yes |
| Built-in iTunes server | Yes |
| Disk scan | Yes |
| On/off switch | Yes |
Software
| Specification | Value |
|---|---|
| Operating system installed | QNAP Turbo System |
| Operating system version | 4.3 |
Power
| Specification | Value |
|---|---|
| Power supply location | External |
| Power supply unit (PSU) capacity | 65 W |
| Number of power supply units | 1 |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 169 mm |
| Depth | 102 mm |
| Height | 219 mm |
| Weight | 1.28 kg |
Packaging content
| Specification | Value |
|---|---|
| External power adapter | Yes |
| Cables included | AC, LAN (RJ-45) |
| Quick start guide | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
