QNAP TS-230 NAS/storage server Tower Realtek RTD1296
QNAP

TS-230 NAS/storage server Tower Realtek RTD1296

2 GB DDR4 0 TB QNAP QTS Blue

Model TS-230Part no. TS-230-6TBEAN 5051868149924

101 specifications
  • ProcessorRealtek
  • Memory2 GB
  • Noise15 dB
  • TypeNAS
  • OSQNAP QTS
  • Weight1.98 kg
See all specifications

Overview

Processor
Realtek
Memory
2 GB
Noise
15 dB
Type
NAS
OS
QNAP QTS
Weight
1.98 kg
Brand
QNAP
Model
TS-230
Part numbers
TS-230-6TB, TS-230-4TB, TS-230/8TB-N300, TS-230/16TB-N300, TS-230/20TB-RED, TS-230/12TB-N300 +34 more
EAN / UPC
5051868149924, 5051868149962, 5051868150005, 5051868149894 +12 more
Also known as
QNAP TS-230 NAS/storage server Tower Realtek RTD1296 2 GB DDR4 0 TB QNAP QTS Blue

Specifications

101 specifications in 14 groups

Storage

Storage drives installedNo
Total installed storage capacity0 TB
Number of storage drives installed0
Number of storage drives supported2
Installed storage drive typeNo
Supported storage drive typesHDD & SSD
Storage drive capacity0 GB
Supported storage drive interfacesSerial ATA II, Serial ATA III
Storage drive sizes supported2.5,3.5"
RAID supportYes
RAID levels0, 1, JBOD
Online RAID migrationYes
Online RAID expansionYes
RAID rebuildYes
Hot-swap drive baysYes
Supported file systemsFAT32, HFS+, NTFS, exFAT, ext3, ext4
Auto-rebuildYes
Bad block scanYes
Disk roamingYes

Processor

Processor manufacturerRealtek
Processor familyRealtek
Processor modelRTD1296
Processor frequency1.4 GHz
Processor cores4

Memory

Internal memory2 GB
Internal memory typeDDR4
Maximum RAM supported2 GB
Flash memory4000 MB

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
DHCP clientYes
DHCP serverYes
Jumbo frames supportYes
iSCSI supportYes
Wake-on-LAN readyYes
Dynamic DNS (DDNS)Yes
WLAN adapter supportedYes

Ports & interfaces

Ethernet LAN (RJ-45) ports1
USB portYes
USB 2.0 ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Fiber ports quantity0

Design

Chassis typeTower
Cooling typeActive
Product colourBlue
Number of fans1 fan(s)
Fan diameter8 cm
LED indicatorsHDD, LAN, Status, USB

Performance

TypeNAS
Device classHome & Home Office
Backup functionYes
Backup featuresCloud, USB drive, iSCSI LUN
BuzzerYes
Multilingual supportYes
Noise level15 dB
Third-party supportYes
Video input channels16 channels
SnapshotYes
Share folder access right managementYes
Web-based managementYes
Access Control List (ACL)Yes
Browser supportedChrome, Firefox, Internet Explorer, Safari
Built-in BitTorrent clientYes
Built-in FTP serverYes
Disk scanYes
Hot spareYes
On/off switchYes
Reset buttonYes
S.M.A.R.T. supportYes
Security algorithms256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
Share folderAFP, CIFS/SMB, FTP
System logYes
USB copy functionYes
Universal Plug and Play (UPnP)Yes

Software

Operating system installedQNAP QTS
Operating system version5.0.0
Windows operating systems supportedWindows 10, Windows 7, Windows 8
Linux operating systems supportedYes
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019

Power

Power supply locationExternal
Power supply unit (PSU) capacity65 W
Number of power supply units1
Power consumption (typical)12.277 W
Power consumption (HDD standby)4.48 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Fan voltage12 V

Weight & dimensions

Width90.2 mm
Depth156.3 mm
Height188.6 mm
Weight1.98 kg
Package weight2.01 kg

Packaging content

External power adapterYes
Cables includedAC, LAN (RJ-45)
Number of screws14

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95%
Storage temperature (T-T)-20 - 70 °C

Logistics data

Harmonized System (HS) code84714100

Other features

Digital Living Network Alliance (DLNA) certifiedYes
