QNAP TS-1635 NAS Desktop Annapurna Labs AL514

4 GB DDR3 0 TB QNAP Turbo System Black

Model TS-1635Part no. TS-1635-4G + 16X ST4000VN008EAN 5051868009105

84 specifications

Overview

Brand: QNAP
Category: NAS & Storage Servers
Model: TS-1635
Part numbers: TS-1635-4G + 16X ST4000VN008, TS-1635-4G, TS-1635-8G, TS-1635-4G + 16X ST2000VN0001, TS-1635-4G + 16X ST3000VN0001, TS-1635-4G + 16X ST4000VN0001 +34 more
EAN / UPC: 5051868009105, 471321351032, 4058154141410, 4713213510322 +36 more
Also known as: QNAP TS-1635 NAS Desktop Annapurna Labs AL514 4 GB DDR3 0 TB QNAP Turbo System Black

84 specifications in 13 groups

Specification	Value
Storage drives installed	No
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	16
Installed storage drive type	No
Supported storage drive types	HDD & SSD
Storage drive capacity	0 GB
Supported storage drive interfaces	Serial ATA, Serial ATA II, Serial ATA III
Storage drive sizes supported	2.5,3.5"
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, 50, 60, JBOD
Supported file systems	FAT32, HFS+, NTFS, ext3, ext4

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000,10000 Mbit/s
Wi-Fi	No
DHCP client	Yes
DHCP server	Yes
Jumbo frames support	Yes
iSCSI support	Yes
Wake-on-LAN ready	Yes
Supported network protocols	CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, SMSC

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB port	Yes
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Fiber ports quantity	2
Fiber optic connector	SFP+

Specification	Value
Type	NAS
Device class	Small & Medium Business
Backup function	Yes
Backup features	Cloud, iSCSI LUN
Multilingual support	Yes
Web-based management	Yes
Access Control List (ACL)	Yes
Browser supported	Internet Explorer 10, Mozilla Firefox 8, Safari 4, Google Chrome
Hot spare	Yes
On/off switch	Yes
Reset button	Yes
S.M.A.R.T. support	Yes
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SNMP, SSH, SSL/TLS
System log	Yes

Specification	Value
Operating system installed	QNAP Turbo System
Operating system version	4.2
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win
Linux operating systems supported	Yes
Mac operating systems supported	Yes
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2

Specification	Value
Power supply location	Built-in
Power supply unit (PSU) capacity	250 W
Number of power supply units	1
Power consumption (typical)	78.45 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Fan voltage	12 V

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%

Specification	Value
Power management	Yes
Software support	Qfinder Pro, myQNAPcloud Connect, Qsync, QNAP NetBak Replicator, vSphere, Q’center, QNAP Snapshot Agent, Qsnap
