TS-130 NAS/storage server Tower Realtek RTD1295
1 GB DDR4 0 TB QNAP QTS White
Model TS-130EAN 4713213518779
75 specifications
- ProcessorRealtek
- Memory1 GB
- Noise15.2 dB
- TypeNAS
- OSQNAP QTS
- Weight610 g
Overview
- Processor
- Realtek
- Memory
- 1 GB
- Noise
- 15.2 dB
- Type
- NAS
- OS
- QNAP QTS
- Weight
- 610 g
- Brand
- QNAP
- Category
- NAS & Storage Servers
- Model
- TS-130
- Part numbers
- TS-130, TS-130+1XST2000VN004, TS-130+1XST4000VN008
- EAN / UPC
- 4713213518779
- Also known as
- QNAP TS-130 NAS/storage server Tower Realtek RTD1295 1 GB DDR4 0 TB QNAP QTS White
Specifications
75 specifications in 13 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | No |
| Total installed storage capacity | 0 TB |
| Number of storage drives installed | 0 |
| Number of storage drives supported | 1 |
| Installed storage drive type | No |
| Supported storage drive types | HDD & SSD |
| Storage drive capacity | 0 GB |
| Storage drive interface | Serial ATA II, Serial ATA III |
| Supported storage drive interfaces | Serial ATA II, Serial ATA III |
| Storage drive sizes supported | 2.5,3.5" |
| Hot-swap drive bays | Yes |
| Supported file systems | FAT32, HFS+, NTFS, ext3, ext4 |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Realtek |
| Processor family | Realtek |
| Processor model | RTD1295 |
| Processor frequency | 1.4 GHz |
| Processor cores | 4 |
| Number of processors supported | 1 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 1 GB |
| Internal memory type | DDR4 |
| Maximum RAM supported | 1 GB |
| Flash memory | 4000 MB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| DHCP client | Yes |
| DHCP server | Yes |
| Jumbo frames support | Yes |
| Wake-on-LAN ready | Yes |
| Dynamic DNS (DDNS) | Yes |
| Link aggregation | Yes |
| WLAN adapter supported | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Cooling type | Active |
| Product colour | White |
| Number of fans | 1 fan(s) |
| Fan diameter | 5 cm |
| LED indicators | HDD, LAN, Status, System |
Performance
| Specification | Value |
|---|---|
| Type | NAS |
| Device class | Home & Home Office |
| Backup function | Yes |
| Buzzer | Yes |
| Noise level | 15.2 dB |
| Disk scan | Yes |
| On/off switch | Yes |
| Reset button | Yes |
| S.M.A.R.T. support | Yes |
| System log | Yes |
Software
| Specification | Value |
|---|---|
| Operating system installed | QNAP QTS |
| Operating system version | 5.0.0 |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8 |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 |
Power
| Specification | Value |
|---|---|
| Power supply location | External |
| Power supply unit (PSU) capacity | 36 W |
| Power consumption (typical) | 7.29 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Fan voltage | 12 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 66.1 mm |
| Depth | 157.6 mm |
| Height | 187.5 mm |
| Weight | 610 g |
| Package weight | 1.22 kg |
Packaging content
| Specification | Value |
|---|---|
| External power adapter | Yes |
| Cables included | AC, LAN (RJ-45) |
| Power cables quantity | 1 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 70 °C |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84714100 |
