QNAP TS-1277XU-RP-2600-8G/144TB GOLD

Model TS-1277XU-RP-2600-8G/144TB GOLDPart no. TS-1277XU-RP-2600-8G/144TB-GOLDEAN 5051868134166

111 specifications

Overview

Brand: QNAP
Category: NAS & Storage Servers
Model: TS-1277XU-RP-2600-8G/144TB GOLD
Part number: TS-1277XU-RP-2600-8G/144TB-GOLD
EAN / UPC: 5051868134166
Also known as: QNAP TS-1277XU-RP-2600-8G/144TB GOLD NAS Rack (2U) AMD Ryzen™ 5 8 GB DDR4 HDD QNAP Turbo System Aluminium, Black

111 specifications in 12 groups

Specification	Value
Storage drives installed	Yes
Total installed storage capacity	144 TB
Number of storage drives installed	12
Number of storage drives supported	12
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Storage drive capacity	12 TB
Storage drive interface	Serial ATA III
Supported storage drive interfaces	Serial ATA II, Serial ATA III
Storage drive sizes supported	2.5,3.5"
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, 50, 60, JBOD
Online RAID migration	Yes
Online RAID expansion	Yes
RAID rebuild	Yes
Hot-swap drive bays	Yes
Supported file systems	FAT32, HFS+, NTFS, ext3, ext4
Auto-rebuild	Yes
Bad block scan	Yes
Disk roaming	Yes

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000,10000 Mbit/s
Ethernet LAN data rate supported (max)	10000 Mbit/s
DHCP client	Yes
DHCP server	Yes
Jumbo frames support	Yes
iSCSI support	Yes
Wake-on-LAN ready	Yes
Dynamic DNS (DDNS)	Yes
Link aggregation	Yes
Supported network protocols	TCP/IP, IPv4, IPv6
WLAN adapter supported	Yes

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB port	Yes
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Fiber ports quantity	2
Fiber optic connector	SFP+
PCI Express x4 (Gen 3.x) slots	2
PCI Express x8 (Gen 3.x) slots	2

Specification	Value
Type	NAS
Device class	Small & Medium Business
Backup function	Yes
Backup features	Cloud, iSCSI LUN
Buzzer	Yes
Multilingual support	Yes
Number of users	4096 user(s)
Noise level	37.2 dB
Third-party support	Yes
Video input channels	8 channels
Snapshot	Yes
Management protocols	SNMP
Share folder access right management	Yes
Web-based management	Yes
Access Control List (ACL)	Yes
Browser supported	Apple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox
Built-in BitTorrent client	Yes
Built-in FTP server	Yes
Built-in iTunes server	Yes
Hot spare	Yes
On/off switch	Yes
Password authentication	Yes
Reset button	Yes
S.M.A.R.T. support	Yes
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SNMP, SSH
Share folder	AFP, CIFS/SMB, FTP
System log	Yes
Universal Plug and Play (UPnP)	Yes

Specification	Value
Operating system installed	QNAP Turbo System
Operating system version	4.3.4
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basi
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016

Specification	Value
Power supply location	Built-in
Power supply unit (PSU) capacity	300 W
Number of power supply units	2
Redundant power supply (RPS) support	Yes
Power consumption (typical)	106.66 W
AC input voltage	100 - 240 V
Fan voltage	12 V

Specification	Value
Cables included	AC
Number of screws	84

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
