QNAP DS420+ NAS Compact Intel® Celeron® J4025
QNAP

DS420+ NAS Compact Intel® Celeron® J4025

2 GB DDR4 16 TB HDD Black

Model DS420+Part no. DS420+/8TB-REDPROEAN 5050914131814

93 specifications
  • ProcessorIntel® Celeron®
  • Memory2 GB
  • Noise19.8 dB
  • TypeNAS
  • ColourBlack
  • Storage drives installedYes
See all specifications

Overview

Processor
Intel® Celeron®
Memory
2 GB
Noise
19.8 dB
Type
NAS
Colour
Black
Storage drives installed
Yes
Brand
QNAP
Model
DS420+
Part numbers
DS420+/8TB-REDPRO, DS420+/16TB-IW, DS420+/16TB-IWP, DS420+/16TB-REDPRO, DS420+/24TB-IW, DS420+/24TB-IWP +15 more
EAN / UPC
5050914131814, 5050914131562, 5050914131678, 5050914131845 +17 more
Also known as
QNAP DS420+ NAS Compact Intel® Celeron® J4025 2 GB DDR4 16 TB HDD Black

Specifications

93 specifications in 15 groups

Storage

Storage drives installedYes
Total installed storage capacity16 TB
Number of storage drives installed4
Number of storage drives supported6
Installed storage drive typeHDD
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial ATA II, Serial ATA III
Storage drive sizes supported2.5,3.5,M.2
Number of M.2 (M & B) slots2
RAID supportYes
RAID levels0, 1, 5, 6, 10, JBOD
Online RAID migrationYes
Online RAID expansionYes
Hot-swap drive baysYes
Supported file systemsBTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4

Processor

Processor manufacturerIntel
Processor familyIntel® Celeron®
Processor modelJ4025
Processor frequency2 GHz
Processor boost frequency2.9 GHz
CPU configuration (max)1

Memory

Internal memory2 GB
Internal memory typeDDR4
Maximum RAM supported6 GB
Memory slots1

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
iSCSI supportYes
Wake-on-LAN readyYes
Link aggregationYes
Supported network protocolsSMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

Ports & interfaces

Ethernet LAN (RJ-45) ports2
USB portYes
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Fiber ports quantity0

Design

Chassis typeCompact
Cooling typeActive
Product colourBlack
Number of fans2 fan(s)
Fan diameter9.2 cm
Drive bay lockingYes
LED indicatorsHDD, Power, Status
Cable lock slotYes
Cable lock slot typeKensington

Performance

TypeNAS
Device classHome & Home Office
Backup functionYes
Backup featuresCloud, iSCSI LUN
Multilingual supportYes
Number of users2048 user(s)
Noise level19.8 dB
Third-party supportYes
SnapshotYes
Share folder access right managementYes
Access Control List (ACL)Yes
Browser supportedChrome, Firefox, Edge, Internet Explorer, Safari
Built-in FTP serverYes
Hot spareYes
On/off switchYes
Password authenticationYes
Reset buttonYes
Security algorithmsHTTPS, SSH, SSL/TLS
Share folderCIFS/AFP/NFS/FTP/WebDAV
System logYes

Software

Windows operating systems supportedYes
Mac operating systems supportedYes

Power

Power supply locationExternal
Power supply unit (PSU) capacity90 W
Power consumption (typical)28.3 W
Power consumption (HDD standby)8.45 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

Weight & dimensions

Width199 mm
Depth223 mm
Height166 mm

Packaging content

External power adapterYes
Cables includedAC, LAN (RJ-45)

Processor special features

Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95%
Operating altitude0 - 5000 m
Storage temperature (T-T)-20 - 60 °C

Logistics data

Harmonized System (HS) code84714100

Other features

Compliance certificatesRoHS
Digital Living Network Alliance (DLNA) certifiedYes
