Origin Storage Thecus W5000

Model Thecus W5000Part no. W5000/10TBEAN 5055146643920

86 specifications

Overview

Brand: Origin Storage
Category: NAS & Storage Servers
Model: Thecus W5000
Part numbers: W5000/10TB, W5000/15TB, W5000/5TBNLSA, W5000/15TBNLSA, W5000/10TBNLSA, W5000/30TBNLSA +5 more
EAN / UPC: 5055146643920, 5055146642183, 5055146643944, 5055146642190 +18 more
Also known as: Origin Storage Thecus 5 Bay W5000 5X3TB SATA HDD

86 specifications in 15 groups

Specification	Value
Storage drives installed	Yes
Total installed storage capacity	15 TB
Number of storage drives installed	5
Number of storage drives supported	5
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Storage drive capacity	3 TB
Storage drive interface	Serial ATA II, Serial ATA III
Storage drive size	3.5"
Supported file systems	FAT32, NTFS, ReiserFS

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	D2550
Processor frequency	1.86 GHz
Processor cores	2
Processor threads	4
Processor cache	1 MB
L2 cache	1 MB
Bus type	DMI
ECC supported by processor	No
Physical Address Extension (PAE)	36 bit
Processor cache type	L2
Processor code	SR0VY
Processor codename	Cedarview
Processor lithography	32 nm
Processor operating modes	64-bit
Processor package size	22 X 22 mm
Processor socket	BGA 559
Stepping	B3
Thermal Design Power (TDP)	10 W
Tjunction	100 C
Maximum internal memory supported by processor	4 GB
Memory bandwidth supported by processor (max)	6.4 GB/s
Conflict-Free processor	No

Specification	Value
Internal memory	2 GB
Internal memory type	DDR3

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	No
Supported network protocols	IPV6/Multiple NICs/DNS/DHCP/WINS

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB port	Yes
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Fiber ports quantity	0
VGA (D-Sub) ports quantity	1
eSATA ports quantity	1
HDMI ports quantity	1

Specification	Value
On-board graphics card base frequency	640 MHz
Number of displays supported (on-board graphics)	2

Specification	Value
Operating system installed	Windows Storage Server 2012 R2 Essentials

Specification	Value
Power supply location	Built-in
Power supply unit (PSU) capacity	200 W
Number of power supply units	1

Specification	Value
External power adapter	No

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	No
Intel 64	Yes
Intel Dual Display Capable Technology	Yes
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	No
Maximum number of PCI Express lanes	4
Physical Address Extension (PAE)	Yes
Memory channels supported by processor	Single
Memory types supported by processor	DDR3-SDRAM

Specification	Value
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80%

Specification	Value
Processor ARK ID	65470
