Origin Storage Thecus N8880U-10G

Origin Storage Thecus N8880U-10G

Model Thecus N8880U-10GPart no. N8880U10G/24TBNASWDEAN 5056006113751

119 specifications
  • ProcessorIntel® Core™ i3
  • Memory8 GB
  • TypeNAS
  • OSThecusOS
  • ColourBlack
  • Storage drives installedNo
See all specifications

Overview

Processor
Intel® Core™ i3
Memory
8 GB
Type
NAS
OS
ThecusOS
Colour
Black
Storage drives installed
No
Brand
Origin Storage
Model
Thecus N8880U-10G
Part numbers
N8880U10G/24TBNASWD, N8880U-10G, N8880U10G/8TBNLWD, N8880U10G/8TBNL, N8880U10G/64TBNL, N8880U10G/48TBNLWD +12 more
EAN / UPC
5056006113751, 5056006102991, 5056006113867, 5056006113799 +14 more
Also known as
Origin Storage Thecus 8 Bay NAS Bare Box No Drives

Specifications

119 specifications in 15 groups

Storage

Storage drives installedNo
Total installed storage capacity0 TB
Number of storage drives installed0
Number of storage drives supported8
Installed storage drive typeNo
Supported storage drive typesHDD & SSD
Storage drive capacity0 GB
Storage drive interfaceSerial ATA II, Serial ATA III
Storage drive size3.5"
RAID supportYes
RAID levels0, 1, 5, 6, 10, 50, 60, JBOD
Hot-swap drive baysYes
Supported file systemsBTRFS, XFS, ext3, ext4

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i3
Processor generation2nd gen Intel® Core™ i3
Processor modeli3-2120
Processor frequency3.3 GHz
Processor cores2
Processor threads4
Processor cache3 MB
Bus typeDMI
CPU configuration (max)1
CPU multiplier (bus/core ratio)33
PCI Express slots version2.0
Processor cache typeSmart Cache
Processor codenameSandy Bridge
Processor lithography32 nm
Processor operating modes64-bit
Processor package size37.5 x 37.5 mm
Processor socketLGA 1155 (Socket H2)
System bus rate5 GT/s
Tcase69.1 °C
Thermal Design Power (TDP)65 W
On-board graphics card modelIntel® HD Graphics 2000
Maximum internal memory supported by processor32 GB
Memory bandwidth supported by processor (max)21 GB/s
Conflict-Free processorNo

Memory

Internal memory8 GB
Internal memory typeDDR3
Maximum RAM supported32 GB

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000,10000 Mbit/s
Ethernet LAN data rate supported (max)10000 Mbit/s
Wi-FiNo
iSCSI supportYes
Data link protocolsTCP/IP/AppleTalk
Supported network protocolsSMB/CIFS, HTTP/HTTPS, FTP, NFS v4, AFP

Ports & interfaces

Ethernet LAN (RJ-45) ports3
USB 2.0 ports quantity6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Fiber ports quantity0
VGA (D-Sub) ports quantity1
HDMI ports quantity1

Graphics

On-board graphics card ID0x102
On-board graphics card base frequency850 MHz
On-board graphics card dynamic frequency (max)1100 MHz
Number of displays supported (on-board graphics)2

Design

Chassis typeRack (2U)
Cooling typeActive
Product colourBlack
LED indicatorsYes
Built-in displayYes
Display typeLCM

Performance

TypeNAS
Device classSmall & Medium Business
Backup functionYes
BuzzerYes
Built-in optical driveNo
Disk scanYes
Hot spareYes
On/off switchYes
S.M.A.R.T. supportYes
Security algorithms256-bit AES

Software

Operating system installedThecusOS
Windows operating systems supportedYes
Linux operating systems supportedYes
Mac compatibilityYes

Power

Power supply locationBuilt-in
Power supply unit (PSU) capacity400 W
Number of power supply units2
Redundant power supply (RPS) supportYes

Weight & dimensions

Width428 mm
Depth586 mm
Height90 mm

Packaging content

External power adapterNo

Processor special features

Embedded options availableYes
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Dual Display Capable TechnologyYes
Intel Enhanced Halt StateYes
Intel FDI TechnologyYes
Intel Fast Memory AccessYes
Intel Flex Memory AccessYes
Intel Identity Protection Technology version1.00
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)No
Intel® AES New Instructions (Intel® AES-NI)No
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® InTru™ 3D TechnologyYes
Intel® Insider™Yes
Intel® Quick Sync Video TechnologyYes
Intel® Turbo Boost TechnologyNo
Intel® Wireless Display (Intel® WiDi)No
Maximum number of PCI Express lanes16
Thermal Monitoring TechnologiesYes
Memory channels supported by processorDual

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C

Other features

Compliance certificatesRoHS
CertificationCE/FCC/C-Tick/VCCI/BSMI WEEE
80 PLUS certification80 PLUS
Processor ARK ID53426
