Origin Storage Thecus N5550 5 Bay NAS

Model Thecus N5550 5 Bay NASPart no. N5550/20TBNLEAN 5056006111429

102 specifications

Overview

Brand: Origin Storage
Category: NAS & Storage Servers
Model: Thecus N5550 5 Bay NAS
Part numbers: N5550/20TBNL, N5550/10TBNASWD, N5550/10TBNAS, N5550/10TBNLWD, N5550/10TBNL, N5550/15TBNAS +11 more
EAN / UPC: 5056006111429, 5056006111344, 5056006111306, 5056006111474 +13 more
Also known as: Origin Storage Thecus N5550 5 Bay NAS 5 x 2TB NAS Drives Installed

102 specifications in 15 groups

Specification	Value
Storage drives installed	Yes
Total installed storage capacity	10 TB
Number of storage drives installed	5
Number of storage drives supported	5
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Storage drive capacity	2 TB
Storage drive interface	Serial ATA II, Serial ATA III
Storage drive size	3.5"
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, JBOD
Hot-swap drive bays	Yes
Supported file systems	BTRFS, XFS, ext3, ext4

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	D2550
Processor frequency	1.86 GHz
Processor cores	2
Processor threads	4
Processor cache	1 MB
L2 cache	1 MB
Bus type	DMI
ECC supported by processor	No
Physical Address Extension (PAE)	36 bit
Processor cache type	L2
Processor code	SR0VY
Processor codename	Cedarview
Processor lithography	32 nm
Processor operating modes	64-bit
Processor package size	22 X 22 mm
Processor socket	BGA 559
Stepping	B3
Thermal Design Power (TDP)	10 W
Tjunction	100 C
Maximum internal memory supported by processor	4 GB
Memory bandwidth supported by processor (max)	6.4 GB/s
Conflict-Free processor	No

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	No
iSCSI support	Yes
Data link protocols	TCP/IP/AppleTalk
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS v4, AFP

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Fiber ports quantity	0
VGA (D-Sub) ports quantity	1
eSATA ports quantity	1
HDMI ports quantity	1
eSATA	Yes

Specification	Value
On-board graphics card base frequency	640 MHz
Number of displays supported (on-board graphics)	2

Specification	Value
Operating system installed	ThecusOS
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Mac compatibility	Yes

Specification	Value
Power supply location	Built-in
Power supply unit (PSU) capacity	200 W
Number of power supply units	1

Specification	Value
External power adapter	No

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	No
Intel 64	Yes
Intel Dual Display Capable Technology	Yes
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	No
Maximum number of PCI Express lanes	4
Physical Address Extension (PAE)	Yes
Memory channels supported by processor	Single
Memory types supported by processor	DDR3-SDRAM

Specification	Value
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80%

Specification	Value
Compliance certificates	RoHS
Certification	CE/FCC/C-Tick/VCCI/BSMI WEEE VMware, Citrix
Processor ARK ID	65470
