Origin Storage Thecus N10850

Model Thecus N10850Part no. N10850/20TBENASWDEAN 5056006114840

146 specifications

Overview

Brand: Origin Storage
Category: NAS & Storage Servers
Model: Thecus N10850
Part numbers: N10850/20TBENASWD, N10850, N10850/40TBENASWD, N10850/40TBNL, N10850/40TBENAS, N10850/40TBNLWD +11 more
EAN / UPC: 5056006114840, 5055146577911, 5056006114864, 5056006114925 +13 more
Also known as: Origin Storage Thecus 10 bay NAS Bare box

146 specifications in 16 groups

Specification	Value
Storage drives installed	No
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	10
Supported storage drive types	HDD & SSD
Storage drive interface	Serial ATA, Serial ATA II, Serial ATA III
Storage drive size	2.5/3.5"
HDD speed	Variable
Maximum supported storage capacity	80 TB
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, 50, 60, JBOD
Hot-swap drive bays	Yes
Supported file systems	BTRFS, ext3, ext4, XFS

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® E3 Family
Processor model	E3-1225
Processor frequency	3.1 GHz
Processor boost frequency	3.4 GHz
Processor cores	4
Processor threads	4
Processor cache	6 MB
L3 cache	6 MB
Bus type	DMI
CPU configuration (max)	1
CPU multiplier (bus/core ratio)	31
ECC supported by processor	Yes
PCI Express slots version	2.0
Processor cache type	Smart Cache
Processor code	SR00G
Processor codename	Sandy Bridge
Processor lithography	32 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor socket	LGA 1155 (Socket H2)
Stepping	D2
System bus rate	5 GT/s
Tcase	72.6 °C
Thermal Design Power (TDP)	95 W
On-board graphics card model	Intel® HD Graphics P3000
Maximum internal memory supported by processor	32 GB
Memory bandwidth supported by processor (max)	21 GB/s

Specification	Value
Internal memory	4 GB
Internal memory type	DDR3

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	No
DHCP client	Yes
DHCP server	No
Quality of Service (QoS) support	No
Jumbo frames support	Yes
iSCSI support	Yes
Wake-on-LAN ready	Yes

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Fiber ports quantity	0
VGA (D-Sub) ports quantity	0
eSATA ports quantity	0
HDMI ports quantity	1
Serial ports quantity	0
RS-232 ports	0
External mini-SAS ports	0
Thunderbolt ports quantity	0

Specification	Value
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2

Specification	Value
Chassis type	Tower
Cooling type	Active
Product colour	Black, Silver
Housing material	Aluminium
Number of fans	1 fan(s)
Drive bay locking	Yes
LED indicators	HDD, LAN, Link, Network, Power, Status
Built-in display	Yes
Display type	OLED

Specification	Value
Operating system installed	Linux
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Mac operating systems supported	Yes
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Home Server 2011, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008
Other operating systems supported	Android, iOS, Windows Embedded Standard 7 64-bit, Windows Phone

Specification	Value
Power supply location	Built-in
Power supply unit (PSU) capacity	400 W
Number of power supply units	1
Redundant power supply (RPS) support	No
AC input voltage	110-240 V

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Demand Based Switching	Yes
Intel Dual Display Capable Technology	Yes
Intel Enhanced Halt State	Yes
Intel FDI Technology	Yes
Intel Fast Memory Access	Yes
Intel Flex Memory Access	Yes
Intel Identity Protection Technology version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Smart Cache	Yes
Intel® Turbo Boost Technology	2.0
Intel® Wireless Display (Intel® WiDi)	No
Maximum number of PCI Express lanes	20
Thermal Monitoring Technologies	Yes
Memory channels supported by processor	Dual
Memory types supported by processor	DDR3-SDRAM

Specification	Value
Sustainability certificates	RoHS

Specification	Value
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80%
