Origin Storage Thecus 3.6TB

Origin Storage Thecus 3.6TB

Model Thecus 3.6TBPart no. N12000-SAS3.6EAN 5055146567691

69 specifications
  • ProcessorIntel® Xeon® 3000 Sequence
  • Memory4 GB
  • Speed1000 Mbit/s
  • ColourBlack, Grey
  • Total installed storage capacity3.6 TB
  • Processor manufacturerIntel
See all specifications

Overview

Processor
Intel® Xeon® 3000 Sequence
Memory
4 GB
Speed
1000 Mbit/s
Colour
Black, Grey
Total installed storage capacity
3.6 TB
Processor manufacturer
Intel
Brand
Origin Storage
Model
Thecus 3.6TB
Part number
N12000-SAS3.6
EAN / UPC
5055146567691
Also known as
Origin Storage Thecus 3.6TB Intel® Xeon® 3000 Sequence X3470 4 GB DDR3 Black, Grey

Specifications

69 specifications in 8 groups

Storage

Total installed storage capacity3.6 TB
Number of storage drives installed12
Number of storage drives supported12
Storage drive capacity300 GB
Storage drive interfaceSerial ATA II
RAID supportYes
RAID levels0, 1, 5, 6, 10, 50, 60, JBOD

Processor

Processor manufacturerIntel
Processor familyIntel® Xeon® 3000 Sequence
Processor modelX3470
Processor frequency2.93 GHz
Processor boost frequency3.6 GHz
Processor cores4
Processor threads8
Processor cache8 MB
L3 cache8 MB
Bus typeDMI
CPU configuration (max)1
CPU multiplier (bus/core ratio)22
ECC supported by processorYes
Number of processors installed1
PCI Express configurations1x16, 2x8, 4x4
PCI Express slots version2.0
Physical Address Extension (PAE)36 bit
Processing Die size296 mm²
Processor cache typeSmart Cache
Processor codeSLBJH
Processor lithography45 nm
Processor operating modes64-bit
Processor package size37.5 x 37.5 mm
Processor socketLGA 1156 (Socket H)
SteppingB1
System bus rate2.5 GT/s
Tcase72.7 °C
Thermal Design Power (TDP)95 W
Maximum internal memory supported by processor32 GB
Memory bandwidth supported by processor (max)21 GB/s

Memory

Internal memory4 GB
Internal memory typeDDR3

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Wi-FiNo
Compliance industry standardsIEEE802.3ab/IEEE802.3/IEEE802.3u
Cabling technology10/100/1000Base-T(X)
Maximum data transfer rate1000 Mbit/s

Ports & interfaces

Ethernet LAN (RJ-45) ports3

Design

Product colourBlack, Grey

Processor special features

Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Demand Based SwitchingYes
Intel Enhanced Halt StateYes
Intel Trusted Execution TechnologyYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)No
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Smart CacheYes
Intel® Turbo Boost Technology1.0
Maximum number of PCI Express lanes16
Number of Processing Die Transistors774 M
Physical Address Extension (PAE)Yes
Thermal Monitoring TechnologiesNo
Memory channels supported by processorDual
Memory types supported by processorDDR3-SDRAM

Other features

Processor ARK ID42932
