NETGEAR RN528X NAS Desktop Intel® Pentium® D1508

4 GB DDR4 16 TB HDD ReadyNAS OS Black, Silver

Model RN528XPart no. RN528X+96TBSEAIWP

140 specifications

Overview

Brand: NETGEAR
Category: NAS & Storage Servers
Model: RN528X
Part numbers: RN528X+96TBSEAIWP, RN528X+16TBSEAIWP, RN528X+32TBSEAIWP, RN528X+48TBSEAIWP, RN528X+64TBSEAIWP, RN528X+80TBSEAIWP +1 more
Also known as: NETGEAR RN528X NAS Desktop Intel® Pentium® D1508 4 GB DDR4 16 TB HDD ReadyNAS OS Black, Silver

140 specifications in 13 groups

Specification	Value
Storage drives installed	Yes
Total installed storage capacity	16 TB
Number of storage drives installed	8
Number of storage drives supported	8
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Storage drive capacity	2 TB
Storage drive interface	Serial ATA
Storage drive size	2.5/3.5"
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, JBOD
Hot-swap drive bays	Yes
Supported file systems	BTRFS, FAT32, HFS+, NTFS, ext3, ext4
Bad block scan	No

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Pentium®
Processor model	D1508
Processor frequency	2.2 GHz
Processor boost frequency	2.6 GHz
Processor cores	2
Processor threads	4
Processor cache	3 MB
CPU configuration (max)	1
ECC supported by processor	Yes
PCI Express configurations	1x16, 1x4, 1x8
PCI Express slots version	2.0, 3.0
Processor cache type	L3
Processor code	SR2DQ
Processor codename	Broadwell
Processor lithography	14 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor socket	BGA 1667
Scalability	1S
Stepping	V2
Thermal Design Power (TDP)	25 W
Maximum internal memory supported by processor	128 GB
Conflict-Free processor	Yes

Specification	Value
Internal memory	4 GB
Internal memory type	DDR4

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10000 Mbit/s
Ethernet LAN data rate supported (max)	10000 Mbit/s
Copper ethernet cabling technology	10GBASE-T
Wi-Fi	No
DHCP client	Yes
Jumbo frames support	Yes
iSCSI support	Yes
Wake-on-LAN ready	Yes
Dynamic DNS (DDNS)	No
Dynamic IP	Yes
Link aggregation	Yes
Load balancing system	Yes
Static IP	Yes
Supported network protocols	TCP/IP, IPv4, IPv6, IEEE 802.3a, SSH, SNMP v2, v3, NTP

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB port	Yes
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
eSATA ports quantity	1

Specification	Value
Type	NAS
Device class	Small & Medium Business
Backup function	Yes
Backup features	Cloud, USB drive, iSCSI LUN
Multilingual support	Yes
Number of users	80 user(s)
Noise level	28 dB
Built-in optical drive	No
Card reader integrated	No
Management protocols	SNMP v2, v3
Web-based management	Yes
Access Control List (ACL)	Yes
Browser supported	Microsoft Internet Exploer 9+, Mozilla Firefox 14+, Google Chrome 20+, Apple Safari 5+
Built-in BitTorrent client	Yes
Built-in FTP server	Yes
Built-in UPnP AV media server	Yes
Built-in iTunes server	Yes
Hot spare	Yes
Network Time Protocol (NTP) client	Yes
On/off switch	Yes
Remotely operated	Yes
S.M.A.R.T. support	Yes
Security algorithms	256-bit AES
Share folder	1024
System log	Yes
Mean time between failures (MTBF)	22618.91 h

Specification	Value
Operating system installed	ReadyNAS OS
Operating system version	6
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Other operating systems supported	Android, Solaris 10, Solaris 11, Solaris 8, Solaris 9, iOS

Specification	Value
Power supply location	Built-in
Power supply unit (PSU) capacity	250 W
Power consumption (typical)	82.2 W
Power consumption (off)	0.341 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Enhanced Halt State	Yes
Intel Identity Protection Technology version	1.00
Intel Secure Key Technology version	1.00
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Maximum number of PCI Express lanes	32
Thermal Monitoring Technologies	Yes
UART	Yes
Memory channels supported by processor	Dual
Memory types supported by processor	DDR3-SDRAM, DDR4-SDRAM

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%

Specification	Value
Compliance certificates	RoHS
Certification	FCC Class B, CE Class B, VCCI Class B
Processor ARK ID	91558
