NETGEAR RN3138-100NES 8TB (4x 2TB Seagate Exos Enterprise HDD)

Model RN3138-100NES 8TB (4x 2TB Seagate Exos Enterprise HDD)Part no. RN3138-100NES/8TB-EXOS

91 specifications

Overview

Brand: NETGEAR
Category: NAS & Storage Servers
Model: RN3138-100NES 8TB (4x 2TB Seagate Exos Enterprise HDD)
Part number: RN3138-100NES/8TB-EXOS
Also known as: NETGEAR RN3138-100NES 8TB (4x 2TB Seagate Exos Enterprise HDD) NAS Rack (1U) Intel Atom® C2558 4 GB Black

91 specifications in 12 groups

Specification	Value
Storage drives installed	Yes
Number of storage drives installed	4
Number of storage drives supported	4
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Storage drive interface	Serial ATA
Storage drive size	2.5/3.5"
RAID support	Yes
RAID levels	0, 1, 5, 6, 10
Hot-swap drive bays	Yes
Supported file systems	FAT32, HFS+, NTFS, ext3, ext4

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	C2558
Processor frequency	2.4 GHz
Processor cores	4
Processor threads	4
Processor cache	2 MB
ECC supported by processor	Yes
PCI Express slots version	2.0
Physical Address Extension (PAE)	36 bit
Processor cache type	L3
Processor code	SR1CZ
Processor lithography	22 nm
Processor operating modes	32-bit, 64-bit
Processor package size	34 x 28 mm
Processor socket	BGA 1283
Stepping	B0
Thermal Design Power (TDP)	15 W
Maximum internal memory supported by processor	64 GB
Conflict-Free processor	No

Specification	Value
Internal memory	4 GB
Flash memory	128 MB

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	1000 Mbit/s
Wi-Fi	No
Jumbo frames support	Yes
iSCSI support	Yes
Wake-on-LAN ready	Yes
Link aggregation	Yes
Load balancing system	Yes
Supported network protocols	TC P/I P, IPv4, IPv6

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB port	Yes
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Fiber ports quantity	0
eSATA ports quantity	2

Specification	Value
Type	NAS
Device class	Large Enterprise Business
Backup function	Yes
Backup features	Cloud
Noise level	28 dB
Network Time Protocol (NTP) client	Yes
S.M.A.R.T. support	Yes
Security algorithms	256-bit AES

Specification	Value
Power supply location	Built-in
Power supply unit (PSU) capacity	180 W
Number of power supply units	1
Power consumption (typical)	55 W
Power consumption (off)	0.3 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz

Specification	Value
Embedded options available	Yes
Execute Disable Bit	Yes
Graphics & IMC lithography	22 nm
Intel 64	Yes
Intel QuickAssist Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Turbo Boost Technology	No
Maximum number of PCI Express lanes	16
Physical Address Extension (PAE)	Yes
UART	Yes
Memory channels supported by processor	Dual
Memory types supported by processor	DDR3-SDRAM, DDR3L-SDRAM

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%

Specification	Value
Certification	FCC B, CE B, RoHS, VCCI B
Processor ARK ID	77983
