NETGEAR ReadyNAS 628X

Model ReadyNAS 628XPart no. RN628XE6-100NESEAN 606449117226

107 specifications

Overview

Brand: NETGEAR
Category: NAS & Storage Servers
Model: ReadyNAS 628X
Part numbers: RN628XE6-100NES, RN628X00-100NES/112TB-IWP, RN628X00-100NES, RN628XE3-100NES, RN628XE4-100NES
EAN / UPC: 606449117226, 606449116748, 606449116786, 606449116823
Also known as: NETGEAR ReadyNAS 628X NAS Mini Tower Intel® Xeon® D D-1521 8 GB DDR4 0 TB Black, Silver

107 specifications in 12 groups

Specification	Value
Storage drives installed	No
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	8
Installed storage drive type	No
Supported storage drive types	SSD
Storage drive interface	Serial ATA III
Storage drive size	2.5/3.5"
RAID support	Yes
RAID levels	0, 1, 5, 6, 10
Hot-swap drive bays	Yes

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® D
Processor model	D-1521
Processor frequency	2.4 GHz
Processor boost frequency	2.7 GHz
Processor cores	4
Processor threads	8
Processor cache	6 MB
CPU configuration (max)	1
ECC supported by processor	Yes
PCI Express configurations	1x16, 1x4, 1x8
PCI Express slots version	2.0, 3.0
Processor code	SR2DF
Processor codename	Broadwell
Processor lithography	14 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor series	Intel Xeon D-1500
Processor socket	BGA 1667
Scalability	1S
Stepping	V2
Thermal Design Power (TDP)	45 W
Maximum internal memory supported by processor	128 GB
Conflict-Free processor	Yes

Specification	Value
Internal memory	8 GB
Internal memory type	DDR4

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Fiber ports quantity	0

Specification	Value
Type	NAS
Backup function	Yes
Web-based management	Yes
Access Control List (ACL)	Yes
Built-in BitTorrent client	Yes
Built-in FTP server	Yes
Built-in UPnP AV media server	Yes
Built-in iTunes server	Yes
Hot spare	Yes
Network Time Protocol (NTP) client	Yes
On/off switch	Yes
Password authentication	Yes
S.M.A.R.T. support	Yes
Share folder	1024
System log	Yes

Specification	Value
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows
Linux operating systems supported	Yes
Mac operating systems supported	Yes
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Other operating systems supported	Android, iOS

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Enhanced Halt State	Yes
Intel Secure Key Technology version	1.00
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Maximum number of PCI Express lanes	32
Thermal Monitoring Technologies	Yes
UART	Yes
Memory channels supported by processor	Dual
Memory types supported by processor	DDR3-SDRAM, DDR4-SDRAM
