NETGEAR ReadyNAS 4360S

Model ReadyNAS 4360SPart no. RR4360S0-10000SEAN 606449117950

110 specifications

Overview

Brand: NETGEAR
Category: NAS & Storage Servers
Model: ReadyNAS 4360S
Part numbers: RR4360S0-10000S, RR4360S+720TBSEAIWP
EAN / UPC: 606449117950
Also known as: NETGEAR ReadyNAS 4360S NAS Rack (4U) Intel® Xeon® E3 v5 E3-1225V5 16 GB DDR4 0 TB Black

110 specifications in 13 groups

Specification	Value
Storage drives installed	No
Total installed storage capacity	0 TB
Number of storage drives installed	0
Installed storage drive type	No
Supported storage drive types	HDD & SSD
Storage drive interface	Serial ATA III
Storage drive size	3.5"
Maximum supported storage capacity	600 TB
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, 50, 60
Hot-swap drive bays	Yes

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® E3 v5
Processor model	E3-1225V5
Processor frequency	3.3 GHz
Processor boost frequency	3.7 GHz
Processor cores	4
Processor threads	4
Processor cache	8 MB
Bus type	DMI3
CPU configuration (max)	1
ECC supported by processor	Yes
PCI Express configurations	1x16, 1x8+2x4, 2x8
PCI Express slots version	3.0
Processor cache type	Smart Cache
Processor codename	Skylake
Processor lithography	14 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor series	Intel Xeon E3-1200 v5
Processor socket	LGA 1151 (Socket H4)
Scalability	1S
System bus rate	8 GT/s
Thermal Design Power (TDP)	80 W
On-board graphics card model	Intel® HD Graphics P530
Maximum internal memory supported by processor	64 GB
Memory bandwidth supported by processor (max)	34.1 GB/s
Conflict-Free processor	Yes

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Fiber ports quantity	2
Fiber optic connector	SFP+
eSATA ports quantity	2
External mini-SAS ports	3

Specification	Value
On-board graphics card DirectX version	12.0
On-board graphics card ID	0x191D
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	400 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
Maximum on-board graphics card memory	1.7 GB
Number of displays supported (on-board graphics)	3

Specification	Value
Power supply location	Built-in
Power supply unit (PSU) capacity	700 W
Number of power supply units	2
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Graphics & IMC lithography	14 nm
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Enhanced Halt State	Yes
Intel Secure Key Technology version	1.00
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	Yes
Intel® Insider™	Yes
Intel® OS Guard	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Secure Key	Yes
Intel® Smart Cache	Yes
Intel® Turbo Boost Technology	2.0
Intel® Wireless Display (Intel® WiDi)	Yes
Maximum number of PCI Express lanes	16
Thermal Monitoring Technologies	Yes
Memory channels supported by processor	Dual
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V

Specification	Value
Harmonized System (HS) code	84714100

Specification	Value
Processor ARK ID	88168
