NETGEAR ReadyNAS 424 Diskless

Model ReadyNAS 424 DisklessPart no. RN42400100NES

114 specifications

Overview

Brand: NETGEAR
Category: NAS & Storage Servers
Model: ReadyNAS 424 Diskless
Part number: RN42400100NES
Also known as: NETGEAR ReadyNAS 424 Diskless NAS Desktop Intel Atom® C3338 2 GB DDR4 0 TB ReadyNAS OS Black

114 specifications in 13 groups

Specification	Value
Storage drives installed	No
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	4
Installed storage drive type	No
Supported storage drive types	HDD & SSD
Storage drive capacity	0 GB
Storage drive interface	Serial ATA III
Supported storage drive interfaces	Serial ATA III
Storage drive size	3.5"
Storage drive sizes supported	3.5"
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, JBOD
Hot-swap drive bays	Yes
Supported file systems	BTRFS, FAT32, HFS+, NTFS, ext3, ext4
Bad block scan	Yes

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	C3338
Processor frequency	1.5 GHz
Processor boost frequency	2.2 GHz
Processor cores	2
Processor threads	2
Processor cache	4 MB
CPU configuration (max)	1
ECC supported by processor	Yes
PCI Express configurations	1x2, 1x4, 1x8
PCI Express slots version	3.0
Processor code	SR36E
Processor codename	Denverton
Processor lithography	14 nm
Processor operating modes	64-bit
Processor package size	34 x 28 mm
Processor socket	BGA 1310
Stepping	B0
Tcase	89 °C
Thermal Design Power (TDP)	9 W
Tjunction	100 °C
Maximum internal memory supported by processor	64 GB
Conflict-Free processor	Yes

Specification	Value
Internal memory	2 GB
Internal memory type	DDR4

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	No
DHCP client	Yes
Jumbo frames support	Yes
iSCSI support	Yes
Wake-on-LAN ready	Yes
Link aggregation	Yes
Supported network protocols	TCP/IP, IPv4, IPv6, SSH, NTP

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB port	Yes
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Fiber ports quantity	0
eSATA ports quantity	1

Specification	Value
Type	NAS
Device class	Home & Home Office
Backup function	Yes
Backup features	Cloud, USB drive, iSCSI LUN
Multilingual support	Yes
Number of users	8192 user(s)
Noise level	24.9 dB
Web-based management	Yes
Access Control List (ACL)	Yes
Browser supported	Microsoft Internet Explorer 9+, Microsoft Edge, Mozilla Firefox 14+, Google Chrome 20+, Apple Safari 5+
Hot spare	Yes
S.M.A.R.T. support	Yes
Security algorithms	256-bit AES, SNMP, SNMPv3, SSH
Share folder	CIFS/SMB, AFP, FTP

Specification	Value
Operating system installed	ReadyNAS OS
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Linux operating systems supported	Yes
Mac operating systems supported	Yes
Server operating systems supported	Windows Server 2008, Windows Server 2012 R2
Other operating systems supported	VMware vSphere ESXi

Specification	Value
Power supply location	External
Power supply unit (PSU) capacity	90 W
Number of power supply units	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Specification	Value
Embedded options available	Yes
Execute Disable Bit	Yes
Intel QuickAssist Technology	No
Intel Secure Boot	Yes
Intel Secure Boot Technology version	1.00
Intel Secure Key Technology version	1.00
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Maximum number of PCI Express lanes	10
Memory channels supported by processor	Single
Memory types supported by processor	DDR3L, DDR4-SDRAM

Specification	Value
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	5 - 95%
