Lenovo EMC px4-300r Storage server Rack (1U) Intel® Celeron® E1500

2 GB DDR3 8 TB HDD EMC LifeLine Black

Model px4-300rPart no. 70BJ9003WW+WD2000F9YZ

91 specifications

Overview

Brand: Lenovo
Category: NAS & Storage Servers
Model: px4-300r
Part numbers: 70BJ9003WW+WD2000F9YZ, 70BJ9003WW + 4X WD20EFRX, 70BJ9003WW + 4X WD30EFRX, 70BJ9003WW + 4X ST2000NC000, 70BJ9003WW + 4X ST2000VN000, 70BJ9003WW + 4X ST2000VX000 +7 more
Also known as: Lenovo EMC px4-300r Storage server Rack (1U) Intel® Celeron® E1500 2 GB DDR3 8 TB HDD EMC LifeLine Black

91 specifications in 13 groups

Specification	Value
Storage drives installed	Yes
Total installed storage capacity	8 TB
Number of storage drives installed	4
Number of storage drives supported	4
Installed storage drive type	HDD
Supported storage drive types	HDD & SSD
Storage drive capacity	2 TB
Storage drive interface	Serial ATA II
Storage drive size	3.5"
RAID support	Yes
RAID levels	0, 1, 5, 10, JBOD
Hot-swap drive bays	Yes
Supported file systems	FAT32, HFS+, NTFS, ext2, ext3

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Celeron®
Processor model	E1500
Processor frequency	2.2 GHz
Processor cores	2
Processor threads	2
Processor cache	0.512 MB
L2 cache	0.5 MB
Bus type	FSB
CPU multiplier (bus/core ratio)	11
FSB Parity	No
Processing Die size	77 mm²
Processor cache type	L2
Processor codename	Conroe
Processor front side bus	800 MHz
Processor lithography	65 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor socket	LGA 775 (Socket T)
Tcase	73.3 °C
Thermal Design Power (TDP)	65 W

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
iSCSI support	Yes
Wake-on-LAN ready	Yes
Supported network protocols	CIFS/SMB/Rally (Microsoft), NFS (Linux/UNIX), AFP/Bonjour (Apple), FTP, SFTP TFTP, HTTP, HTTPS, WebDAV, Windows DFS, SNMP

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	3

Specification	Value
Chassis type	Rack (1U)
Product colour	Black

Specification	Value
Operating system installed	EMC LifeLine
Operating system version	4.0
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Mac operating systems supported	Yes
Pre-installed software	McAfee VirusScan Enterprise

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Demand Based Switching	No
Intel Enhanced Halt State	Yes
Intel Trusted Execution Technology	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Turbo Boost Technology	No
Number of Processing Die Transistors	105 M
Thermal Monitoring Technologies	Yes

Specification	Value
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	8 - 85%
Non-operating altitude	0 - 12192 m
Operating altitude	0 - 2286 m
Storage relative humidity (H-H)	5 - 95%
Storage temperature (T-T)	-40 - 60 °C

Specification	Value
Processor ARK ID	35100
