Lenovo EMC px4-300r Diskless

Model EMC px4-300r DisklessPart no. 70BJ9012EAEAN 888228173306

80 specifications

Overview

Brand: Lenovo
Category: NAS & Storage Servers
Model: EMC px4-300r Diskless
Part number: 70BJ9012EA
EAN / UPC: 888228173306
Also known as: Lenovo TotalStorage Series EMC px4-300r Diskless Storage server Rack (1U) Intel® Celeron® E1500 2 GB DDR3 0 TB Black

80 specifications in 12 groups

Specification	Value
Storage drives installed	No
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	4
Supported storage drive types	HDD
Storage drive capacity	0 GB
Storage drive interface	Serial ATA, Serial ATA II
Storage drive size	3.5"
Maximum supported storage capacity	16 TB
RAID support	Yes
RAID levels	0, 1, 5, 10
Hot-swap drive bays	Yes
Supported file systems	FAT32, NTFS

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Celeron®
Processor model	E1500
Processor frequency	2.2 GHz
Processor cores	2
Processor threads	2
Processor cache	0.512 MB
L2 cache	0.5 MB
Bus type	FSB
CPU multiplier (bus/core ratio)	11
FSB Parity	No
Processing Die size	77 mm²
Processor cache type	L2
Processor codename	Conroe
Processor front side bus	800 MHz
Processor lithography	65 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor socket	LGA 775 (Socket T)
Tcase	73.3 °C
Thermal Design Power (TDP)	65 W

Specification	Value
Internal memory	2 GB
Internal memory type	DDR3

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	No
Supported network protocols	CIFS/SMB/Rally, NFS, AFP Bonjour, FTP, SFTP, TFTP, HTTP, WebDAV, Windows DFS

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Fiber ports quantity	0

Specification	Value
Chassis type	Rack (1U)
Product colour	Black

Specification	Value
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Win
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Demand Based Switching	No
Intel Enhanced Halt State	Yes
Intel Trusted Execution Technology	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Turbo Boost Technology	No
Number of Processing Die Transistors	105 M
Thermal Monitoring Technologies	Yes

Specification	Value
Processor ARK ID	35100
