Iomega StorCenter px2-300d Desktop Intel Atom® D525

2 GB DDR3 4 TB Black

Model px2-300dPart no. 36181EAN 4019976361813

84 specifications

Overview

Brand: Iomega
Category: NAS & Storage Servers
Model: px2-300d
Part numbers: 36181, 36197
EAN / UPC: 4019976361813, 742709361975
Also known as: Iomega StorCenter px2-300d Desktop Intel Atom® D525 2 GB DDR3 4 TB Black

84 specifications in 14 groups

Specification	Value
Total installed storage capacity	4 TB
Number of storage drives installed	2
Number of storage drives supported	2
Storage drive capacity	2 TB
Storage drive interface	Serial ATA II
Storage drive size	3.5"
RAID support	Yes
RAID levels	0, 1, JBOD
Supported file systems	ext2, ext3, FAT32, HFS+, NTFS
Average latency	4.17 ms

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	D525
Processor frequency	1.8 GHz
Processor cores	2
Processor threads	4
Processor cache	1 MB
L2 cache	1 MB
Bus type	DMI
ECC supported by processor	No
Number of processors installed	1
Physical Address Extension (PAE)	32 bit
Processing Die size	87 mm²
Processor cache type	L2
Processor code	SLBXC
Processor codename	Pineview
Processor lithography	45 nm
Processor operating modes	64-bit
Processor package size	22 x 22 mm
Processor socket	BGA 559
Stepping	B0
Thermal Design Power (TDP)	13 W
Tjunction	100 °C
Maximum internal memory supported by processor	4 GB
Memory bandwidth supported by processor (max)	6.4 GB/s
Conflict-Free processor	No

Specification	Value
Internal memory	2 GB
Internal memory type	DDR3

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	No
iSCSI support	Yes
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Cabling technology	10/100/1000Base-T(X)

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
VGA (D-Sub) ports quantity	1

Specification	Value
Chassis type	Desktop
Product colour	Black

Specification	Value
Multilingual support	Yes
Noise level	29.5 dB
Mean time between failures (MTBF)	1200000 h

Specification	Value
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vi
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion

Specification	Value
Power consumption (typical)	28 W
AC input voltage	100-240 V

Specification	Value
Cables included	LAN (RJ-45)

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	No
Execute Disable Bit	Yes
Idle States	No
Intel 64	Yes
Intel Demand Based Switching	No
Intel Enhanced Halt State	No
Intel Trusted Execution Technology	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	No
Number of Processing Die Transistors	176 M
Thermal Monitoring Technologies	No
Memory channels supported by processor	Single

Specification	Value
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	8 - 85%

Specification	Value
Minimum system requirements	Internet Explorer 7.0, Firefox 3.x
Networking features	Gigabit Ethernet
Processor ARK ID	49490
