Dell PowerVault NX3100 NAS

Dell PowerVault NX3100 NAS

Model PowerVault NX3100 NASPart no. 210-31556

63 specifications
  • ProcessorIntel® Xeon® 5000 Sequence
  • OSWindows Storage Server 2008
  • Number of storage drives supported12
  • Processor manufacturerIntel
  • Internal memory typeDDR3
  • Supported network protocolsCIFS, NFS, FTP
See all specifications

Overview

Processor
Intel® Xeon® 5000 Sequence
OS
Windows Storage Server 2008
Number of storage drives supported
12
Processor manufacturer
Intel
Internal memory type
DDR3
Supported network protocols
CIFS, NFS, FTP
Brand
Dell
Model
PowerVault NX3100 NAS
Part number
210-31556
Also known as
DELL PowerVault NX3100 NAS Rack (2U) Intel® Xeon® 5000 Sequence E5620 DDR3 Windows Storage Server 2008

Specifications

63 specifications in 9 groups

Storage

Number of storage drives supported12
Storage drive interfaceSerial Attached SCSI (SAS)
Storage drive size2.5/3.5"
Maximum supported storage capacity24 TB
Hot-swap drive baysYes
Supported file systemsNTFS

Processor

Processor manufacturerIntel
Processor familyIntel® Xeon® 5000 Sequence
Processor modelE5620
Processor frequency2.4 GHz
Processor boost frequency2.66 GHz
Processor cores4
Processor threads8
Processor cache12 MB
L2 cache12 MB
Bus typeQPI
CPU configuration (max)2
CPU multiplier (bus/core ratio)18
ECC supported by processorYes
Number of processors installed2
Physical Address Extension (PAE)40 bit
Processor cache typeSmart Cache
Processor codeSLBV4
Processor lithography32 nm
Processor operating modes64-bit
Processor package size42.5 X 45 mm
Processor socketSocket B (LGA 1366)
SteppingB1
System bus rate5.86 GT/s
Tcase77.6 °C
Thermal Design Power (TDP)80 W
Maximum internal memory supported by processor288 GB
Memory bandwidth supported by processor (max)25.6 GB/s
Conflict-Free processorNo

Memory

Internal memory typeDDR3
Maximum RAM supported24 GB

Network

Supported network protocolsCIFS, NFS, FTP

Design

Chassis typeRack (2U)

Software

Operating system installedWindows Storage Server 2008

Power

Redundant power supply (RPS) supportYes

Processor special features

Embedded options availableYes
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Demand Based SwitchingYes
Intel Enhanced Halt StateYes
Intel Trusted Execution TechnologyYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost Technology1.0
Number of QPI links2
Thermal Monitoring TechnologiesNo
Memory channels supported by processorTriple

Other features

Compatible operating systemsWindows Storage Server
Dimensions (WxDxH)445.2 x 664.6 x 86.7 mm
Processor ARK ID47925
Data protection featuresSIS, DFS-R, VSS
Expansion slots2 x PCIex4 1 x PCIex8
RAID controller typeH700
