EMC Storage NX3240
Model EMC Storage NX3240Part no. EMEA_NX3240
60 specifications
- ProcessorIntel® Xeon®
- Memory16 GB
- TypeNAS
- ColourBlack
- Storage drives installedYes
- Processor manufacturerIntel
Overview
- Processor
- Intel® Xeon®
- Memory
- 16 GB
- Type
- NAS
- Colour
- Black
- Storage drives installed
- Yes
- Processor manufacturer
- Intel
- Brand
- Dell
- Category
- NAS & Storage Servers
- Model
- EMC Storage NX3240
- Part number
- EMEA_NX3240
- Also known as
- DELL EMC Storage NX3240 NAS Intel® Xeon® 3104 16 GB 6 TB HDD Black
Specifications
60 specifications in 9 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | Yes |
| Total installed storage capacity | 6 TB |
| Number of storage drives installed | 1 |
| Installed storage drive type | HDD |
| Supported storage drive types | HDD & SSD |
| Storage drive capacity | 600 GB |
| Storage drive interface | Near Line SAS (NL-SAS) |
| Storage drive size | 2.5" |
| RAID support | Yes |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® |
| Processor generation | 1st Generation Intel® Xeon® Scalable |
| Processor model | 3104 |
| Processor frequency | 1.7 GHz |
| Processor cores | 6 |
| Processor threads | 6 |
| Processor cache | 8.25 MB |
| L3 cache | 8.25 MB |
| PCI Express slots version | 3.0 |
| Processor cache type | L3 |
| Processor code | SR3GM |
| Processor codename | Skylake |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor package size | 76.0 x 56.5 mm |
| Processor socket | LGA 3647 (Socket P) |
| Scalability | 2S |
| Stepping | U0 |
| Tcase | 78 °C |
| Thermal Design Power (TDP) | 85 W |
| Maximum internal memory supported by processor | 768 GB |
| Conflict-Free processor | Yes |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
Design
| Specification | Value |
|---|---|
| Cooling type | Active |
| Product colour | Black |
| Number of fans | 6 fan(s) |
| LED indicators | Yes |
Performance
| Specification | Value |
|---|---|
| Type | NAS |
| Device class | Large Enterprise Business |
| Built-in optical drive | Yes |
| Optical drive type | DVD±RW |
Power
| Specification | Value |
|---|---|
| Number of power supply units | 1 |
| Power consumption (typical) | 750 W |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
Processor special features
| Specification | Value |
|---|---|
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Intel 64 | Yes |
| Intel TSX-NI | Yes |
| Intel TSX-NI version | 1.00 |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Turbo Boost Technology | No |
| Maximum number of PCI Express lanes | 48 |
| Memory types supported by processor | DDR4-SDRAM |
Other features
| Specification | Value |
|---|---|
| Processor ARK ID | 123546 |
