DNS-1200-05 NAS Mini Tower CN5230
0.512 GB 10 TB Black, Grey
Model DNS-1200-05Part no. DNS-1200-05-15TB
41 specifications
- ProcessorCN5230
- Memory0.512 GB
- TypeNAS
- ColourBlack, Grey
- Storage drives installedYes
- Processor manufacturerCavium
Overview
- Processor
- CN5230
- Memory
- 0.512 GB
- Type
- NAS
- Colour
- Black, Grey
- Storage drives installed
- Yes
- Processor manufacturer
- Cavium
- Brand
- D-Link
- Category
- NAS & Storage Servers
- Model
- DNS-1200-05
- Part numbers
- DNS-1200-05-15TB, DNS-1200-05-10TB, DNS-1200-05-10TB-SEA, DNS-1200-05-15TB-RED, DNS-1200-05-15TB-SEA, DNS-1200-05-20TB +5 more
- Also known as
- D-Link DNS-1200-05 NAS Mini Tower CN5230 0.512 GB 10 TB Black, Grey
Specifications
41 specifications in 10 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | Yes |
| Total installed storage capacity | 10 TB |
| Number of storage drives supported | 5 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | Serial ATA, Serial ATA II |
| RAID support | Yes |
| RAID levels | 0, 1, 5+S, 5, 6, JBOD |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Cavium |
| Processor model | CN5230 |
| Processor cores | 4 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 0.512 GB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Jumbo frames support | Yes |
| iSCSI support | Yes |
| Dynamic DNS (DDNS) | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB port | Yes |
| USB 2.0 ports quantity | 2 |
Design
| Specification | Value |
|---|---|
| Chassis type | Mini Tower |
| Cooling type | Active |
| Product colour | Black, Grey |
| Number of fans | 2 fan(s) |
| Built-in display | Yes |
| Display type | OLED |
Performance
| Specification | Value |
|---|---|
| Type | NAS |
| Device class | Home & Home Office |
| Backup function | Yes |
| On/off switch | Yes |
| Security algorithms | SNMP |
Power
| Specification | Value |
|---|---|
| Power supply location | Built-in |
| Power supply unit (PSU) capacity | 200 W |
| Power consumption (typical) | 55 W |
| Power consumption (sleep) | 25.2 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 167 mm |
| Depth | 273 mm |
| Height | 260 mm |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -20 - 70 °C |
