Buffalo TeraStation WS5220DN NAS Desktop Intel Atom® C3338

Buffalo TeraStation WS5220DN NAS Desktop Intel Atom® C3338

8 GB DDR4 4 TB HDD Windows Server IoT 2025 Black

Model WS5220DNPart no. WS5220DN08S9EAN 747464134680

52 specifications
  • ProcessorIntel Atom®
  • Memory8 GB
  • TypeNAS
  • OSWindows Server IoT 2025
  • Weight4.72 kg
  • ColourBlack
See all specifications

Overview

Processor
Intel Atom®
Memory
8 GB
Type
NAS
OS
Windows Server IoT 2025
Weight
4.72 kg
Colour
Black
Brand
Buffalo
Model
WS5220DN
Part numbers
WS5220DN08S9, WS5220DN04W5, WS5220DN08W5, WS5220DN08W6EU, WS5220DN04W6EU, WS5220DN04W6 +1 more
EAN / UPC
747464134680, 747464136448, 747464136431, 4981254047262 +3 more
Also known as
Buffalo TeraStation WS5220DN NAS Desktop Intel Atom® C3338 8 GB DDR4 4 TB HDD Windows Server IoT 2025 Black

Specifications

52 specifications in 12 groups

Storage

Storage drives installedYes
Total installed storage capacity4 TB
Number of storage drives installed2
Number of storage drives supported2
Installed storage drive typeHDD
Supported storage drive typesHDD
Storage drive capacity2 TB
Storage drive interfaceSerial ATA III
RAID supportYes
RAID levels0, 1, JBOD

Processor

Processor manufacturerIntel
Processor familyIntel Atom®
Processor modelC3338
Processor frequency2.2 GHz
Processor cores2

Memory

Internal memory8 GB
Internal memory typeDDR4
ECCYes

Network

Ethernet LANYes
Ethernet LAN data rates100,1000,10,10000 Mbit/s
Ethernet LAN data rate supported (max)10000 Mbit/s
Copper ethernet cabling technology10GBASE-T, 1000BASE-T, 2.5GBASE-T, 100BASE-TX, 10BASE-T
iSCSI supportYes
Supported network protocolsTCP/IP

Ports & interfaces

Ethernet LAN (RJ-45) ports3
USB portYes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2

Design

Chassis typeDesktop
Cooling typeActive
Product colourBlack

Performance

TypeNAS
Device classSmall & Medium Business
Backup functionYes
Security algorithmsSNMP

Software

Operating system installedWindows Server IoT 2025
Windows operating systems supportedWindows 11, Windows 10, Windows 8.1
Mac operating systems supportedMac OS X 10.12 Sierra
Server operating systems supportedWindows Server 2022, Windows Server 2019, Windows Server 2016, Windows Server 2012 R2, Windows Server 2012

Power

Power consumption (max)85 W
AC input voltage100-240 V
AC input frequency50/60 Hz

Weight & dimensions

Width170.1 mm
Depth231.1 mm
Height170.1 mm
Weight4.72 kg
Package width309.8 mm
Package depth358.1 mm
Package height320 mm
Package weight4.99 kg

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 85%

Other features

Digital Living Network Alliance (DLNA) certifiedYes
