TeraStation TS6400DN0802 NAS/storage server Tower Intel Atom® C3538
8 GB 8 TB HDD Linux Black
Model TS6400DN0802EAN 747464134284
55 specifications
- ProcessorIntel Atom®
- Memory8 GB
- TypeNAS
- OSLinux
- Weight7.4 kg
- ColourBlack
Overview
- Processor
- Intel Atom®
- Memory
- 8 GB
- Type
- NAS
- OS
- Linux
- Weight
- 7.4 kg
- Colour
- Black
- Brand
- Buffalo
- Category
- NAS & Storage Servers
- Model
- TS6400DN0802
- Part number
- TS6400DN0802
- EAN / UPC
- 747464134284
- Also known as
- Buffalo TeraStation TS6400DN0802 NAS/storage server Tower Intel Atom® C3538 8 GB 8 TB HDD Linux Black
Specifications
55 specifications in 12 groups
Storage
| Specification | Value |
|---|---|
| Total installed storage capacity | 8 TB |
| Number of storage drives supported | 4 |
| Installed storage drive type | HDD |
| Supported storage drive types | HDD |
| Storage drive interface | Serial ATA |
| Supported storage drive interfaces | Serial ATA |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Hot-swap drive bays | Yes |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Atom® |
| Processor model | C3538 |
| Processor frequency | 2.1 GHz |
| Processor cores | 4 |
| CPU configuration (max) | 1 |
| Conflict-Free processor | Yes |
Memory
| Specification | Value |
|---|---|
| Internal memory | 8 GB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,1000,10000 Mbit/s |
| Ethernet LAN data rate supported (max) | 10000 Mbit/s |
| iSCSI support | Yes |
| Supported network protocols | TCP/IP, UDP |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Cooling type | Active |
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Type | NAS |
| Device class | Home & Home Office |
| Backup function | Yes |
| Web-based management | Yes |
Software
| Specification | Value |
|---|---|
| Operating system installed | Linux |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8 |
| Mac operating systems supported | Mac OS X 11.0 Big Sur |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 85 W |
| Power consumption (typical) | 61 W |
| Power consumption (HDD standby) | 6 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 170 mm |
| Depth | 215 mm |
| Height | 230 mm |
| Weight | 7.4 kg |
Processor special features
| Specification | Value |
|---|---|
| Embedded options available | Yes |
| Execute Disable Bit | Yes |
| Intel QuickAssist Technology | Yes |
| Intel Secure Boot | Yes |
| Intel Secure Boot Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 85% |
