TeraStation TS3430RN NAS Rack (1U) Alpine AL524
2 GB DDR4 8 TB HDD Black
Model TS3430RNPart no. TS3430RN0802EAN 747464136301
47 specifications
- ProcessorAlpine
- Memory2 GB
- TypeNAS
- Weight6.3 kg
- ColourBlack
- Storage drives installedYes
Overview
- Processor
- Alpine
- Memory
- 2 GB
- Type
- NAS
- Weight
- 6.3 kg
- Colour
- Black
- Storage drives installed
- Yes
- Brand
- Buffalo
- Category
- NAS & Storage Servers
- Model
- TS3430RN
- Part numbers
- TS3430RN0802, TS3430RN0804, TS3430RN1602, TS3430RN1604, TS3430RN0402
- EAN / UPC
- 747464136301, 747464136318, 747464136325, 747464136332 +1 more
- Also known as
- Buffalo TeraStation TS3430RN NAS Rack (1U) Alpine AL524 2 GB DDR4 8 TB HDD Black
Specifications
47 specifications in 10 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | Yes |
| Total installed storage capacity | 8 TB |
| Number of storage drives installed | 4 |
| Number of storage drives supported | 4 |
| Installed storage drive type | HDD |
| Supported storage drive types | HDD & SSD |
| Storage drive capacity | 2 TB |
| Storage drive interface | Serial ATA III |
| Supported storage drive interfaces | Serial ATA III |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Hot-swap drive bays | Yes |
| Supported file systems | BTRFS |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Annapurna Labs |
| Processor family | Alpine |
| Processor model | AL524 |
| Processor frequency | 2 GHz |
| Processor cores | 4 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 2 GB |
| Internal memory type | DDR4 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000,2500 Mbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (1U) |
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Type | NAS |
| Device class | Home & Home Office |
| Backup function | Yes |
| Web-based management | Yes |
| On/off switch | Yes |
| Password authentication | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 85 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 429.2 mm |
| Depth | 429.2 mm |
| Height | 43.1 mm |
| Weight | 6.3 kg |
| Package width | 535.9 mm |
| Package depth | 584.2 mm |
| Package height | 200.6 mm |
| Package weight | 12.4 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | 10 - 85 °C |
